5
NO.DESCRIPTION PART NO.
ERV110S
SIDE PORTS
ERV110T
TOP PORTS
ERV120S
SIDE PORTS
HRV120S
SIDE PORTS
HRV120T
TOP PORTS
ERV120T
TOP PORTS
1OVAL PORT (FITS 5” DIAMETER DUCTS) SV16040 1 1 1 1 1 1
2DOOR LATCH WITH SCREWS SV16035 2 2 2 2 2 2
3OVAL PORT WITH INTEGRATED BALANCING DAMPER SV16041 2 2 2 2 2 2
4
MOTOR & WHEEL ASSEMBLY (5 µF MOTOR CAPACITOR
AND INLET RING INCLUDED)
SV18301 2 2 2 2 2 2
5CAPACITOR 5 µF (2) SV16042 2 2 1 1 1 1
6CAPACITOR 18 µF SV61127 1 1 1 1 1 1
7ELECTRONIC BOARD
SV16038 1 1 1 N/A N/A 1
SV62257 N/A N/A N/A 1 1 N/A
8ERV
FOAM FILTER (2) SV16031 2 2 1 N/A N/A 1
9ERV CORE (WITH 2 FILTERS) SV16037 1 1 1 N/A N/A 1
10 DRAIN CONNECTOR KIT SV03203 N/A N/A N/A 1 1 N/A
11 DOOR ASSEMBLY SV16096 1 1 1 1 1 1
12 BLUE HRV CORE (WITH 2 FILTERS) SV18300 N/A N/A N/A 1 1 N/A
13 HRV FOAM FILTER SV16032 N/A N/A N/A 1 1 N/A
14 MOTORIZED DAMPER PORT ASSEMBLY SV16029 1 1 1 1 1 1
15* ES TRANSFORMER SV18302 1 1 1 1 1 1
16* GREEN TERMINAL BLOCK SV16416 1 1 1 1 1 1
REPLACEMENT PARTS AND REPAIR
In order to ensure your ventilation unit remains in good working condition, you must use Broan genuine replacement parts only.
The Broan genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable
certification standards and maintain a high standard of safety. Any third party replacement part used may cause serious damage
and drastically reduce the performance level of your unit, which will result in premature failing. Also, Broan recommends to contact a
certified service depot for all replacement parts and repairs.
* NOT SHOWN.
1. SERVICE PARTS (CONT'D)
