INSTALLATION MANUAL
SERVICE PARTS
28
KEY
NO.
P
ART NO.DESCRIPTION
QUANTITY
30"
S
TAINLESS
30"
W
HITE
30"
B
LACK
1
S97020030 R
ECIRCULATION COVER PLATE, WHITE (INCLUDING SCREWS)1
S97020031 R
ECIRCULATION COVER PLATE, STAINLESS STEEL (INCLUDING SCREWS)1
S97020029 R
ECIRCULATION COVER PLATE, BLACK (INCLUDING SCREWS)1
2 SR680508 7'' R
OUND DUCT PLATE (INCLUDING SCREWS)111
3 S97020534 3¼”
X 10” DAMPER ASSEMBLY (INCLUDING SCREWS)111
4 S97020408 B
LOWER MOTOR (INCLUDING 4 SCREWS AND 1 CAPACITOR)111
5 S97020407 F
ANPELLER (INCLUDING ITEM 6) 1 1 1
6 SR99420635 C
LIP FOR FANPELLER 111
7 S99010434-002 G
REASE FILTER - MICRO MESH - TYPE C2 (SET OF 2) 1 1 1
8
S97020422 E
LONGATED ROCKER SWITCH, GREY (INCLUDING SCREWS)1
S97020421 E
LONGATED ROCKER SWITCH, WHITE (INCLUDING SCREWS)1
S97020420 E
LONGATED ROCKER SWITCH, BLACK (INCLUDING SCREWS)1
9 S97020448 W
IRE HARNESS 111
* S98011637 W
IRING COVER 111
* S97020292
P
ARTS BAG INCLUDING: 4 METAL SCREWS NO. 8-18 X 1/2”,
6 R
OUND HEAD NO. 8 X 5/8” WOOD SCREWS,
6
NO. 8 X 1/2” COUNTERSUNK SCREWS, 1 SUCTION CUP TOOL
111
* S97020466
N
ON-DUCTED FILTER - TYPE XC (SET OF 2)
(NON-DUCTED INSTALLATION ONLY)
111
* S99527587 N
ON-DUCTED FILTER CLIP KIT (INCLUDES 4 CLIPS)111
* S97020470 E
ASY INSTALL KIT (INCLUDING HARDWARE)111
* SV05921 S
HIELDED HALOGEN BULB 50 W, GU10 2 2 2
BKSH1 SERIES
* ITEM NOT SHOWN.
REPLACEMENT PARTS AND REPAIRS
In order to ensure your unit remains in good working condition, you must use Broan-NuTone LLC or Venmar Ventilation ULC genuine
replacement parts only. Broan-NuTone LLC or Venmar Ventilation ULC genuine replacement parts are specially designed for each
unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety. Any third
party replacement part used may cause serious damage and drastically reduce the performance level of your unit, which will result in
premature failing. Broan-NuTone LLC and Venmar Ventilation ULC recommend to contact a certified service depot for all replacement
parts and repairs.
