No.
Part Code Description Qty
Serie3 Serie4
1 1 S97020534 3-1/4'' X 10'' ADAPTOR/DAMPER (INCL. SCREWS) 1
2 2 SR680508 7'' ROUND DUCT ADAPTOR (INCL. SCREWS) 1
3 3 S1115687 RECIRCULATION COVER PLATE, WHITE (INCL. SCREWS) 1
3 3 S1115689
RECIRCULATION COVER PLATE, STAINLESS STEEL
(INCL. SCREWS)
1
5 5 S1115693
INFRARED SENSING CONTROL FOR GLA3/
MTR3/ALT3/ALT4
1
7&9&10 7&9&10 S1116679 HARNESS KIT FOR GLA3/MTR3/ALT3/ALT4 1 set
8 8 S1116689 HEAT SENSOR FOR GLA3/MTR3/ALT3/ALT4 1
10 10 S97020444 LED MODULE (PAIR) 1
/ 12 S1116684 CCW MOTOR FOR ALT4 (INCL. SCREWS) 1
12 / S1115696 CCW MOTOR FOR GLA3/MTR3/ALT3 (INCL.SCREWS) 1
/ 13 S1116683 CW WHEEL FOR TWIN MOTORS (INCL. SCREWS) 1
13 / S1115695 CW MOTOR FOR GLA3/MTR3/ALT3 (INCL. SCREWS) 1
14 14 S1116682 CCW WHEEL FOR TWIN MOTORS (INCL. SCREWS) 1
15 15 S1116681 CW WHEEL FOR TWIN MOTORS (INCL. SCREWS) 1
16 16 S1115694 BLOWER GUARD DUAL BLOWER (INCL. SCREWS) 2
/ 17 S1116686
MAIN PCB INFRARED CONTROL (INCL. HARDWARE)
FOR ALT4
1
17 / S1115691
MAIN PCB INFRARED CONTROL (INCL. HARDWARE)
FOR GLA3/MTR3/ALT3
1
/ 18 S1116680
CAPACITOR 5uF DUAL BLOWER (INCL. HARDWARE)
FOR ALT4
18 / S1115692
CAPACITOR 4uF DUAL BLOWER (INCL. HARDWARE)
FOR GLA3/MTR3/ALT3
1
19
19 S1115697
WIRING COVER DUAL BLOWER FOR 30'' HOOD (INCL.
SCREW)
1
/ S1116685
WIRING COVER DUAL BLOWER FOR 36'' HOOD (INCL.
SCREW)
1
20
20 S97020204-002 GREASE FILTER - HYBRID 30'' HOOD (SET OF 2)
1 set
/ S97020204-003 GREASE FILTER - HYBRID 36'' HOOD (SET OF 2) 1 set
21 21 S1115686 PARTS BAG INCLUDING EZ1 BRACKETS 1 set
/ 22 S1116687 3-1/4'' X 14'' ADAPTOR/DAMPER (INCL. SCREWS) 1
