10
For ALT4 Serie
Maximum duct lengths recommended
to achieve 80% exhaust efficiency
3¼” X10”
HORIZONTAL
MAXIMUM
DUCT LENGTH
3¼” X10”
VERTICAL
MAXIMUM
DUCT
LENGTH
3¼” X14”
HORIZONTAL
MAXIMUM
DUCT
LENGTH
3¼” X14”
VERTICAL
MAXIMUM
DUCT
LENGTH
7" ROUND
MAXIMUM
DUCT
LENGTH
ROOF OR
WALL CAP
WITH
DAMPER
ELBOW(S)*
(90° AND/OR
45°)
43 ft.
62 ft.
94 ft.
114 ft.
59 ft.
1
0
34 ft.
54 ft.
84 ft.
104 ft.
44 ft.
1
1
26 ft.
45 ft.
74 ft.
94 ft.
30 ft.
1
2
* Standard elbows with 1” internal radius
NOTE: 6" round ducting is possible but may reduce exhaust efficiency.
Contents
Before proceeding to the installation, check the contents of the box. If items are missing or
damaged, contact the manufacturer. Make sure that the following items are included:
No. ITEM PIC QTY
1 HOOD
1
2 7” ROUND DUCT
1
3 3¼” x10” DUCT
1
4 PART BAG
1
5 FILTER
2
6 CRT FUNCTION SWITCH CARD
1
7
3 1/4 x14" DUCT
for ALT4 only
1
