8
3. INSTALL THE UNIT (CONT’D)
3.4 PLANNING OF THE DUCTWORK
• Keep it simple. Plan for a minimum number of bends and joints. Keep the
length of the insulated ducts to a minimum.
• Do not use wall cavities as ducts. Do not use branch lines smaller than
4’’ (102 mm) diameter.
• Do not ventilate crawl spaces or cold room. Do not attempt to recover the
exhaust air from a dryer or a range hood, this would cause the clogging
of the unit.
• Be sure to plan at least one exhaust register on the highest lived-in level
of the house, if it has 2 floors or more.
3.5 INSTALLING 6” DUCTS AND REGISTERS
3.5.1 STALE AIR EXHAUST DUCTWORK
CAUTION
If ducts have to go through an unconditioned space, always use insulated
ducts (purchase separately).
• Install the stale air exhaust register(s) in the main area where the
contaminants are produced: kitchen, living room, etc. Position the
register(s) as far from the stairway as possible and in such a way that the
air circulates in all the lived-in spaces in the house.
• If a register is installed in the kitchen, it must be located at least 4 feet (1.2 m)
from the range.
• Install the register(s) 6 to 12 inches (152 to 305 mm) from the ceiling on
an interior wall OR install it in the ceiling.
• Attach one end of the 6’’ flexible duct to the stale air exhaust register, and
the other end to the unit stale air from building port, using tie wrap and
duct tape.
WARNING
!
Never install a stale air exhaust register in a room where a combustion
device operates, such as a gas water heater, a gas furnace or a fireplace.
3.5.2 FRESH AIR DISTRIBUTION DUCTWORK
• Install the fresh air distribution register(s) in a large, open area in the
lowest level to ensure the greatest possible air circulation. Keep in mind
that the fresh air register(s) must be located as far as possible from the
stale air register(s).
• Install the register(s) in the ceiling OR 6 to 12 inches (152 to 305 mm)
from the ceiling on an interior wall. The duct length should be at least
15’ (4.6 m). (The cooler air will then cross the upper part of the room and
mix with room air before descending to occupant level.)
• Attach one end of the 6’’ flexible duct to the fresh air distribution register,
and the other end to the unit fresh air to building port, using tie wrap and
duct tape.
