VI. Troubleshooting
A. No water flow
Cause: Water intake closed.
Troubleshooting: Open the water intake at the upstream shut-o valve and
check hoses for kinks.
B. No or low water flow in spite of open water intake
Cause: Mains pressure too low.
Troubleshooting: Check mains pressure. If the fault continues, check the filter
system and filter cartridge and replace if necessary. Check
hoses for kinks.
C. Leak
Cause: Screw connections not fitted correctly.
Troubleshooting: Check mains pressure. Fixing all screw connections in
accordance with chapter IV. Check if thread inserts are
tightened to the limit and fixation clips are seated correctly
according to chapter IV. Check gaskets are undamaged and
inserted correctly.
VII. Technical Data
Filter cartridge
Operating pressure 2 bar to max. 6.9 bar
Water intake temperature 4°C to 30°C
Ambient temperature 4°C to 40°C
Water temperature 4°C to 30°C
Flow Rate Max. 3 L/Min.
Working flow range and associated pressure loss 30–180 L/h / 0.2–1.6 bar
Weight (dry/wet) 0.5kg / 1.0kg
Rated filter capacity 8000 L
Chlorine reduction NSF 42 Class I (≥ 50%)
Particle retention NSF 42 Class I (≥ 0.5 μm)
Chlorine reduction DIN EN 14898 Class I (≥ 90%)
Benzene reduction NSF 53 ≥ 90%
Bacteria reduction ASTM F838 99.999%
Cysts reduction 99.95%
Metals reduction (e.g. lead) DIN EN 14898 > 90%
Reduction of medical residues,
pesticides and hormones (e.g. naproxen, lindane,
estrone) NSF 401
> 90%
Herbicides NSF 53 > 84.2%
Asbestos reduction NSF 53 > 99.9%
Dimensions
(Width/Depth/
Height)
Filter system
(filter head with filter
cartridge)
72 mm/69 mm/330 mm
Filter cartridge 68 mm/68 mm/311 mm
Installed dimensions
(vertical installation with
wall mounting)
85 mm/82 mm/330 mm
Operating position Horizontal and vertical
Water inlet connection G3/8”
Water outlet connection G3/8”
