B r i g h t e r P i x e l S t r o b e I P
8 |
CLAMP INSTALLATION
When mounting the fixture to a truss, be sure to secure appropriately rated
professional grade rigging clamps to the included Omega Brackets using an M10
screw fitted through the center hole of the Omega Brackets. This fixture requires the
installation of two Omega brackets and two clamps for secure truss mounting. The fixture also
provides built- in rigging points for a SAFETY CABLE. Be sure to only use the designated rigging point
for the safety cable and never secure a safety cable to a carrying handle.
SAFETY CABLE:
ALWAYS ATTACH A SAFETY CABLE WHENEVER
INSTALLING THIS FIXTURE IN A SUSPENDED
ENVIRONMENT TO ENSURE THAT THE
FIXTURE WILL NOT FALL IF THE CLAMP FAILS.
INSTALLATION GUIDELINES
POWER AND DATA CABLES
TO MAINTAIN THE IP65 RATING INTEGRITY OF THE FIXTURE, ALL
CABLES MUST BE RUN TOWARDS THE GROUND IN ORDER TO
PREVENT WATER ACCUMULATION AROUNDTHE CONNECTIONS.
RJ4 5 DATA CABLES
THE INCLUDED RJ45 DATA CABLE IS FOR FIXTURE TO FIXTURE
INTERCONNECTIONS ONLY! THE RJ45 CABLE CONNECTORS
MAY NOT BE COMPATIBLE WITH OTHER RJ4 5 OR ETHERNET
TYPE CONNECTORS.
INSTALLATION GUIDELINES
POWER AND DATA CONNECTIONS
ENSURE ALL CONNECTIONS AND END CAPS ARE PROPERLY
SEALED WITH A DIELECTRIC GREASE ( AVAILABLE AT MOST
ELECTRICAL SUPPLIERS) IN ORDER TO PREVENT WATER
CORROSION AND/ OR ELECTRICAL SHORT CIRCUIT.
TO MAINTAIN IP65 RATING INTEGRITY AND PREVENT
WATER FROM ENTERING THE FIXTURE, SEAL ALL UNUSED
CONNECTION RUBBER CAPS.
