6
Operating Instructions
Mobile Bluetooth LED oodlight
TORAN 3000 MB 5000 MB 5001 MB 5002 MB
Note: Before using the oodlight, please carefully read the operating instructions and store them
in a proper location!
SAFETY INSTRUCTIONS
1. Before use, always check the oodlight for any possible damage.
Never use the oodlight in case of any damage. If this is the case, please refer to an electrician
or the manufacturer’s service address.
Non-compliance poses a risk of fatal injury from electrical current!
2. Never open the device. The oodlight does not contain components that require
maintenance.
3. The LEDs are not exchangeable.
4. Do not use the oodlight in explosive atmospheres with ammable liquids, gases or dusts.
Risk of death!
5. Keep the oodlight away from children. Children are not aware of the risks imposed by
electric current.
6. Disconnect the oodlight from the mains power and switch the oodlight o before
cleaning.
7. To avoid dazzling or blinding, do not look directly into the light.
TECHNICAL DATA
Radio frequency: 2.4 GHz
Frequency band: 2402 – 2480 MHz
Transmitting power: 9.55 dBm (max.)
Bluetooth version: 5.0
Nominal voltage: 220 – 240 V~ 50/60 Hz
Operating temperature: – 20° C – + 40° C
Model TORAN 3000 MB TORAN 5000 MB TORAN 5001 MB TORAN 5002 MB
Power socket:
—
DE F CH
220 – 240 V~; max 3000 W 220 – 240 V~; max 2000 W
Child protection: — Yes Yes No
Cable: H07RN-F 2G1.0 mm² H07RN-F 3G1.5 mm² H07RN-F 3G1.5 mm² H07RN-F 3G1.5 mm²
Electrical Power: 30 W 46 W 46 W 46 W
Current: 0.13 A 0.22 A 0.22 A 0.22 A
IP class: IP55 IP54 IP54 IP54
Safety class: II I I I
Power factor: 0.9 0.9 0.9 0.9
Dimensions: 276 x 276 x 68 mm 276 x 276 x 68 mm 276 x 276 x 68 mm 276 x 276 x 68 mm
Weight: 2.17 kg 2.75 kg 2.75 kg 2.75 kg
max. projected area: 0.08 m² 0.08 m² 0.08 m² 0.08 m²
This LED oodlight is suitable for indoor and outdoor lighting purposes.
18P126 Mobiler Bluetooth LED Strahler Toran 3000_5000_5001_5002MB 190819.indd 6 19.08.2019 13:54:52
