9
This battery LED light is suitable for lighting purposes both indoors and outdoors and is intended
SAFETY INSTRUCTIONS
•
address.
• Do not look directly into the light.
• Open the device only to replace used batteries.
• A destroyed protective cover must be replaced with an original Brennenstuhl® protective
cover before the light can be used again.
• The light is protected against water spray. Never submerge the headlight in water or other
liquids.
• Do not use the light in potentially explosive environments – mortal danger!
• Use only quality batteries for replacement.
INSTALLATION AND PUTTING IN THE BATTERIES
1. Preparation: (Fig. 2)
Open the fastening screw (Fig. 2.1) by unscrewing it slightly.
Press the release button (Fig. 2.2) and pull the mounting plate out of the housing with
Fig. 2.3).
2. Installation: (Fig. 3 – 4)
The light is attached with the mounting plate.
The recommended installation height is between 1.8 and 2.5 m. (Fig. 3)
Mark the position of the drill holes for fastening the mounting plate and drill the correspon-
ding holes in the wall (Fig. 3+4).
Fasten the mounting plate to the wall with the supplied (or other suitable) screws.
3. Equipping with batteries (Fig. 5)
Install the batteries in the battery compartment. First put the “removal tape” under the
batteries. The correct polarity of the batteries is shown in the battery compartment.
4. Att
ach light (Fig. 6)
Press the release button (Fig. 6.1) and press the light onto the screwed-on mounting plate
(Fig. 6.2). Tighten the fastening screw (Fig. 6.3).
5. Aim light (Fig. 8)
The light can be tilted up to 40° downward and 130° upward. To tilt it, loosen the side screw,
set the desired tilt, and fasten the screw again. The light can also be turned +/-78°.
Battery LED Light LUFOS
029820 BA_LUFOS 200_400 0498620.indd 9 20.07.20 11:54
