AL X050, AL X050 P Operating Instructions
When attaching the spotlight, make sure that the motion detector reacts most sensitively to
device.
ADJUST MOTION DETECTOR
Rotate the mounted spotlight upward. You will see three controls on the bottom of the motion
detector (Fig. 9).
(Fig. 10)
The sensitivity determines the maximum distance at which the sensor switches on due to a
person's movements.
(Fig. 10)
The light setting determines the brightness at which the spotlight's sensor switches on. The
position (sun symbol - right) shows that the sensor works during the day and at night, in the
other position (moon symbol - left), the sensor works only at night.
To set, wait until the desired brightness is reached in the surroundings. Set the time sensor
TIME to the minimum time (10 sec.). Turn the light setting control completely to the symbol
(moon). Turn the control slowly toward the symbol (sun) until the spotlight switches on from
movement.
The sensor will not switch on when detecting a motion beginning with the set brightness.
(Fig. 10)
With this control, you can select any switch-on time between approx. 10 seconds and 4
minutes after the last movement has been detected. Turning the TIME control in the clockwise
direction increases the time period, and reduces it in the anti-clockwise direction.
MOTION DETECTOR: PASSIVE INFRARED SENSOR
Detection range: up to 12 m / up to 180° (horizontal)
Time setting: approx. 10 sec. to 4 min.
SCOPE OF DELIVERY
LED-spotlight, operating instructions, screws, dowels.
ACCESSORIES
Suitable accessories are available on our homepage www.brennenstuhl.com.
MAINTENANCE
ATTENTION: The LED lamp does not contain
components that require maintenance. The light
source in this lamp cannot be replaced; if the
light source has reached the end of its service
life, the entire lamp has to be replaced. The lamp
may not be opened.
