8
S19224 Installation
1/25/2024 Bradley • 215-1686 Rev. S: ECO 23-05-001A
S19224 shown with Eyewash and Plastic Bowl
Dimensions
All dimensions assume standard thread engagement. Variations in manufacturing allow for +/-
1
⁄8"
(3mm) per threaded joint. To find the tolerance of a dimension, add the number of thread joints
across the length of the dimension and multiply it by
1
⁄8" (3mm).
Dust Cover
Eyewash Bowl
13"
(330mm)
34¾"
(883mm) to
floor
35½"
(902mm) to
floor
13¼"
(337mm)
19
11
⁄16"
(470mm)
S19-430EH Drench Hose Foot Pedal Activation
27¼"
(692mm) to
floor
21
1
⁄8"
(537mm) to
floor
1
3
⁄16"
(30mm)
13⁄16"
(30mm)
21"
(533mm)
Water Flow Rate
Eyewash 4–5¼ gpm
Eye/Face Wash 4–5¼ gpm
Body Wash 2–8 gpm
36 5/8"
(931mm)
24 3/4"
(630mm)
NPT Connections BSPP Connections
