Installation S19-500 Series & S19-505 Series
Bradley • 215-1910 Rev. D: ECO 21-05-013 7/6/2021
Parts List
Item Part No. Qty Description Item Part No. Qty Description
1 S45-3009 1 Flow Control Kit (1.5 gpm & 2.2 gpm) 28 160-329 1 Screw, 6-32 x 3/8 RD
2 S53-357 1 Spout w/ Swivel Lock Feature 29 152-073 1 Quarter Groove Pin 3/16 x 1
3 107-675 1 Cover 30 143-075 1 Gear - Middle
4 118-358 1 Adapter - Spout 31 128-211 2 Handle, S19-500W & S19-505W
(S19-500T & S19-505T (Qty 1))
5 125-001CB 2 O-Ring 32 121-031 2 Bonnet Nut, S19-500W & S19-505
(S19-500T & S19-505T (Qty 1))
6 143-076 1 Gear - Spout 33 S73-060 1 Valve, Faucet / Cold Water, S19-500W
& S19-505T
7 124-116 1 Gasket 33A S73-060A 1 Valve Cartridge Cold - Service
8 104-157 1 Spacer - Mounting ns S73-061A 1 Valve Cartridge Hot - Service
9 159-488 1 Mounting Plate ns S73-061 1 Valve, Faucet / Hot Water, S19-500W
& S19-500T
10 160-478 2 Screw, 4-40 x 3/8 Pan 34 142-157B 1 Washer, Lever Blue, S19-500W &
S19-505W
11 161-154 2 Nut, 10-32 Hex Lock 34 142-157R 1 Washer, Lever Red, S19-500W &
S19-505W
12 147-050 2 Stud, 10-32 x 2 34 142-157W 1 Washer, Lever Chrome, S19-500T &
S19-505T
13 269-2789 1 Hose, SS M12-1 x 1/2-14 NPSM 35 160-562 2 Screw, 10-24 x 3 OV, S19-500W &
S19-505W (S19-500T &
S19-505T (Qty 1))
14 269-2788 1 Hose, M8-1 x 3/8 Compression 36 S73-062 1 Valve Body Assembly, S19-500M &
S19-505M
15 160-560 2 Screw, 8-32 x 3 36A S73-062A 1 Valve Cartridge - Service
16 173-032 1 Strainer - Plastic - Slotted 36B S73-062B 1 Handle - Service
17 125-175 1 Flow Control 4.8 36C S73-062C 1 Hose Kit (all 3) - Service
18 S05-189 1 Sprayhead Assembly 36D S73-062D 1 Hardware Mounting - Service
19 125-157 2 O-Ring (-117) 0.799 ID x 0.103 W 37 113-006DH 2 Pipe, 1/2 x Close Red Brass
20 115-159 1 Body - Cap 38 269-1999 3 Comp FTG 1/2 NPTF x 3/8 OD
21 166-012 2 Pin Hinge 39 269-653 4 Hose, Flexible 1/2 NPT 24 LG
22 107-604 2 Dust Cover, Eye Wash 40 269-1150 1 Tee, 1/2"
23 171-010 1 Body Mount 3/8 NPT Female 41 114-051 1 Eyewash Sign
24 113-1333 1 Pipe, 3/8 x 2 Chrome 42 204-421 1 Inspection Tag
25 152-072 1 Pin, 3/16 x 3/4 43 142-137 1 Friction Washer
26 143-074 1 Gear - Large, Swivel 44 142-158 1 Wave Washer
27 142-002AQ 1 Washer, 0.203 x 0.438 x 0.032 Flat
