16 Owner’s Manual

4. Attach the Handlebar Post Adjustment Knob and Handlebar Track

Tighten the Handlebar Post Adjustment Knob (6) into the mount on the Frame. For easier installation of the Handlebar Track, it may be

helpful to adjust the Handlebar Post height. To adjust it, loosen the Knob and pull to disengage the pop pin as you support the post to

prevent it from dropping. Move the Handlebar Post to the desired position.

NOTICE: Do not cut or pinch the cable.

Do not lift the Handlebar Post above the “STOP” mark on the Handlebar Post.

Release the Adjustment Knob to lock the pop pin in the desired hole in the Handlebar Post. Be sure that the pin is fully engaged,then fully

tighten the Adjustment Knob.

Align the Track on the Handlebar Post and fully tighten the screws.

2

4 mm

C

X4

6

Assembly
