Owner’s Manual 13

Assembly

1B. Attach Rear Stabilizer to Frame

Some components of the machine can be heavy or awkward. Use a second person when doing the assembly steps involving these

parts. Do not do steps that involve heavy lifting or awkward movements on your own.

Remove packaging material (P2) from Rear Stabilizer bracket. Place it under the frame in front of the bracket to support the rear of the

machine.

Pivot the Rear Stabilizer onto the mount posts in the bracket and push forward into position. Fully tighten the hardware and remove the

packaging material.

Make sure the hardware is fully tightened.

10

7

P2

6 mm

A

X4

7

10

A

P2

10

P2

7

Rear stabilizer (Left side)
