Using the side panel Auxiliary Input

Use the side panel mini plug AUX INPUT to connect

a portable media device.*

*When a cable is inserted into the AUX INPUT, the rear

panel Analog audio input is muted, and the Aux Input

is played (input mode light is red).

Connect Power

Connect the soundbar power supply

and power cord to the soundbar. Connect

the subwoofer power cord to the subwoofer.

Plug both into AC power outlets.

Turn ON the rear panel power switches on the

soundbar and subwoofer. The wireless subwoofer

connects to the soundbar automatically.

If you plan to use more than one TVee system,

please refer to the Wireless ID section on page 9.

Turn on the system

Use the front panel Power Button 10 to turn on the system. The system will automatically

turn on when audio is playing the analog or optical digital input. The Power/Remote light

indicates green when the system is turned on, and red when the system is turned oﬀ.

Power/Remote Light (4)

Green: Power on.

Red: Power oﬀ.

Note: The lights only illuminate temporarily to show a mode or function change.

How do I watch TV?

Select an input

Use the front panel Input Button 9 to choose an input. Each time the button is pressed,

the input changes in sequence from optical digital input to analog audio input to

Bluetooth input back to optical digital. The color of the Input Mode Light indicates which

input is selected.

Input Mode Light (3)

Green: Optical Digital Input is selected.

Red: Analog Input is selected.

Blue: Bluetooth Input is selected.

HEADPHONE

OUTPUT

AUX IN

(side view)

1 2 3 4

WIRELESS ID

POWER

LOCATION

TABLE WALL

TVee

Model 30

DC IN

24V

3.0A

WIRELESS ID
