Installation and connection en
3.
Push the water outlet hose as far
as it will go into the connecting
piece.
4.
Empty the condensation container.
Page28
5.
Remove the stopper from the un-
derside and insert it in the re-
cess in the top .
6.
Insert the condensation container.
Page28
7.
Connect the appliance to the water
drain.
Page13
Tip: To collect condensation in the
condensation container again (e.g. if
you change where the appliance is
located), carry out these steps in re-
verse order.
Water outlet connection types
ATTENTION
In the event of a blocked or covered
outlet, accumulated wastewater can
flow back into the appliance.
Before operating the appliance, en-
sure that the wastewater drains
away quickly and eliminate any
blockages.
Drainage into a
siphon.
Secure the con-
nection point with
a (12-22 mm)
hose clamp.
Secure the water
outlet hose with a
hose guide at a
height of at least
80 cm and no
more than 100
cm.
Note: You can
use the Y-distrib-
utor
Page24
to connect the wa-
ter outlet hose of
an additional ap-
pliance, such as a
washing machine,
to the same si-
phon outlet.
Drainage into a
wash basin.
Push the water
outlet hose fully
through the elbow
and secure it us-
ing fixing material.
Secure the elbow
at a height of no
more than 100
cm.
Drainage into a
gully.
Push the water
outlet hose fully
through the elbow
and secure it us-
ing fixing material.
Secure the elbow
to the gully.
4.5 Aligning the appliance
In order to reduce vibrations and
noises, align the appliance correctly.
13
