8
Installation on a drawer or cupboard
WARNING‒Risk of burns!
The accessible parts may become hot during opera-
tion.
If there is no built-in oven underneath the hob and
the underside of the hob is accessible, follow these
instructions:
For gas hobs with wok burner, insert a non-flamable
intermediate floor (e.g. metal or ply-Wood) at a dis-
tance of 10 mm from the hob .
→Fig.
4
For gas hobs without a wok burner, it is advisable to
fit an intermediate floor underneath the hob .
→Fig.
5
In both cases, the distance from the intermediate
floor to the mains connection for the appliance must
be at least 10 mm.
The thickness of the separator must allow for re-
specting the distances in the figure.
Installation above an oven
→Fig.
6
Positioning the appliance
1. Position the hob with the upper side facing down
on a flat, stable surface.
2. Apply the adhesive seal supplied to the lower
edge of the hob. The adhesive seal prevents the
penetration of liquids.
→Fig.
7
3. Screw the brackets supplied into the specified po-
sition so that they can turn freely.
→Fig.
8
4. Turn the hob around and insert it into the recess.
Insert the hob in the front of the recess.
→Fig.
9
5. Turn the brackets and tighten them fully.
→Fig.
10
The position of the brackets depends on the work-
top thickness.
Note:Do not use silicone to bond the appliance to
the worktop.
Removing the appliance
1. Disconnect the appliance from the electricity and
gas connections.
2. Unscrew the brackets and proceed in reverse or-
der.
Connecting the gas
Observe the country-specific guidelines.
CAUTION‒Risk of explosion!
A gas leakage may cause an explosion.
▶
If any connection is handled, check the seal.
¡ Arrange the gas connection so that the shut-off
valve is accessible.
¡ Ensure that the information on the rating plate re-
garding the gas type and gas pressure complies
with the local connection conditions.
¡ Connect the appliance to a fixed gas pipe or a flex-
ible metal pipe.
¡ The flexible metal pipe must not come into contact
with the moving parts of the unit in which the appli-
ance is installed (e.g. a drawer) and must not be
routed through any spaces which might become ob-
structed.
¡ Gas connection elbow on the appliance: R 1/2.
¡ Do not move or twist the gas connection elbow.
Connection to gas cylinder or liquid gas tank
▶
If the flame is large or unstable, check that the
regulator of the gas cylinder or liquid gas tank is
working properly.
Note:You can install an overpressure safety device
that limits or cuts off the gas supply if the regulator
of the gas cylinder or liquid gas tank fails.
Spare parts for gas connection
If the country's regulations allow, you can obtain the
gas connection parts from the technical customer
service.
→Fig.
11
Gas connection R 1/2
→Fig.
12
Gas connection G 1/2
1. Replace the gas connection elbow on the appli-
ance with the gas connection elbow G 1/2 sup-
plied in the accessory bag.
→Fig.
13
2. Insert the seal between the gas connection of the
appliance and the gas supply.
Electrical connection
¡ This appliance is type Y: The connection cable must
only be replaced by technical customer service and
not by the user. The cable type and the minimum
cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
¡ The power cable must only be replaced with a cable
from the original manufacturer. This is available
from after-sales service.
¡ Do not use extension cables or multiple socket
strips.
¡ Only connect appliances that are fitted with a plug to
a correctly installed socket with protective earth con-
ductor.
¡ Connect the appliance to a fixed installation and set
up appropriate isolating switches in accordance with
the installation regulations.
→Fig.
14
¡ BN: Brown
¡ BU: Blue
¡ GN/YE: Green and yellow
Converting the gas type
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
customer service. The table →Fig. shows the right
combination for the relevant burner and gas type.
Economy burner
Standard-output burner
High-output burner
Mini-wok multi-crown burner
Wok multi-crown burner
Adjusting the taps
1. Set the control elements to the minimum power
level and pull them out. Remove the plinth for the
control elements.
