en Installation instructions
2.
With the tip of the screwdriver, push down on the flex-
ible rubber holder to access the bypass screw.
Never remove the sealing ring. The sealing rings pre-
vent liquids and dirt from finding their way into the ap-
pliance and impairing its ability to function properly.
3.
Adjust the bypass screws:
A: For ULPG, the bypass screws must be tightened
properly.
B: For Natural Gas, the bypass screws must finish
flush with the fitting.
Injectors
Request change-over injectors from our customer service deparment. Refer injector chart below for sizes.
Burner NG
Hourly gas con-
sumption (MJ)
NG
Injector mark
ULPG
Hourly gas con-
sumption (MJ)
ULPG
Injector mark
Economy burner 4.00 88 3.20 50
Standard-output
burner
6.85 116 5.50 66
High-output burner 11.00 153 9.70 87
Wok multi-crown
burner
13.50 170 13.00 98
Replacing the injectors
1.
Remove all pan supports, burner caps and distribut-
ors.
2.
Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
Ensure that the nozzle does not become detached
during removal or fastening.
Reinstalling the appliance
Install the appliance components in reverse order.
Checking if equipment is working
1.
Check that turning the rotary knob between the posi-
tion for maximum power and the position for min-
imum power does not cause the burner to go out or
result in backfire.
2.
If the gas flow from the burner is not correct, check
whether the nozzle and the position of the bypass
screw are correct.
"Injectors", Page10
"Adjusting the taps", Page9
Documenting the gas type conversion
Attach the sticker showing the new gas type near to
the rating plate.
10
