1. Secure the sealing ring and the pipe to the appli-
ance's gas inlet manifold and tighten the trim ring.
Insert the rubber hose into the end of the pipe and
tighten the screw on the hose clamp.
→Fig.
13
2. Secure the pipe to the appliance's gas inlet mani-
fold and tighten the trim ring. Insert the rubber
hose into the end of the pipe and tighten the
screw on the hose clamp.
→Fig.
14
3. Insert the rubber hose into the end of the pipe and
tighten the screw on the hose clamp.
→Fig.
15
Electrical connection
¡ This appliance is type Y: The connection cable
must only be replaced by technical customer ser-
vice and not by the user. The cable type and the
minimum cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
¡ The power cable must only be replaced with a
cable from the original manufacturer. This is avail-
able from after-sales service.
¡ Do not use extension cables or multiple socket
strips.
¡ Only connect appliances that are fitted with a plug
to a correctly installed socket with protective earth
conductor.
¡ Connect the appliance to a fixed installation and
set up appropriate isolating switches in accord-
ance with the installation regulations.
→Fig.
16
¡ BN: Brown
¡ BU: Blue
¡ GN/YE: Green and yellow
Converting the gas type
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
customer service. The table →Fig.
22
shows the
right combination for the relevant burner and gas
type.
Economy burner
Standard output burner
High output burner
Mini-wok multi-crown burner
Mini-wok multi-crown burner
Adjusting the taps
1. Set the control elements to the minimum power
level and pull them out. Remove the plinth for the
control elements.
2. To access the bypass screw, use the tip of the
screwdriver to push down on the flexible rubber
holder.
→Fig.
17
, →Fig.
18
Never remove the sealing ring. Sealing rings pre-
vent liquids and dirt from finding their way into the
appliance and impairing its ability to function prop-
erly.
3. When adjusting the bypass screws (M) with a slot-
ted-head screwdriver, refer to the table.
‒ A: Firmly tighten the bypass screws.
‒ B: Turn the bypass screws until the gas flow
from the burners is correct.
Replacing the nozzles
1. Remove all pan supports, burner caps and distrib-
utors.
2. Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
→Fig.
19
, →Fig.
20
, →Fig.
21
Ensure that the nozzle does not become detached
during removal or fastening.
Reinstalling the appliance
▶ Install the appliance components in reverse order.
Checking if equipment is working
1. Check that turning the rotary knob between the
position for maximum power and the position for
minimum power does not cause the burner to go
out or result in backfire.
2. If the gas flow from the burner is not correct:
‒ In the table, check whether the nozzle and the
bypass screw are correct.
‒ Tighten or loosen the bypass screw until the
gas flow from the burner is correct.
Documenting the gas type conversion
▶ Attach the sticker showing the new gas type near
to the rating plate.
es
Montaje seguro
Tener en cuenta estas indicaciones de seguridad al
montar el aparato.
¡ Lea atentamente estas instrucciones.
¡ Las imágenes representadas en estas instruccio-
nes tienen carácter orientativo.
¡ Solamente un montaje profesional conforme a las
instrucciones de montaje puede garantizar un uso
seguro del aparato. El instalador es responsable
del funcionamiento perfecto en el lugar de instala-
ción.
¡ Después de realizar la conexión, efectuar una
prueba de estanqueidad.
ADVERTENCIA‒Riesgo de explosión!
Un escape de gas puede provocar una explosión.
▶ Todos los trabajos de instalación, conexión, regu-
lación y adaptación a otro tipo de gas deben ser
realizados por un técnico especialista autorizado y
de conformidad con los reglamentos y disposicio-
nes legales vigentes y los reglamentos de las
compañías locales suministradoras de electrici-
dad y gas. Debe prestarse especial atención a la
normativa aplicable a la ventilación. Para los tra-
bajos de adaptación a otro tipo de gas, recomen-
damos ponerse en contacto con el Servicio de
Atención al Cliente.
ADVERTENCIA‒Peligro: magnetismo!
Atención al magnetismo
Atención para las personas con marcapa-
sos
En las bases de los mandos y en los mandos hay
instalados imanes permanentes. Los imanes pueden
