33
Installing the air expulsion accessories for
the air-conditioning function
There are a set of accessories used to expel
hot air (see "Description of accessories").
Installation for the dehumidification and air
purification function
❏ Remove the diffusion duct and set the air
expulsion tube to the position shown in
fig. 11.
❏ The expulsion tube may also be totally
dismantled if desired.
Fig. 11
Instructions for Use
Installing the suction pad
❏ Open the window slightly and position the
diffusion duct between the jamb and the
glaze frame.
❏ Close the window as far as possible and
secure it with the suction pad supplied,
Fig. 12.
Fig. 12
Installing the sliding window / balcony
accessory
❏ The sliding window/balcony installation
accessory supplied with your appliance can
also be used (See "Description of
accessories"), Fig. 13 : a, b, c, d. This
accessory can be used for both horizontal
and vertical windows.
a
b
c
d
Fig. 13
❏ The accessory has two holes on the side to
fit it to the window / balcony with. The user
can secure it to the frame or wall with two
screws (not included with the accessory) to
prevent it from moving or falling out of
place, Fig. 14.
