en Cleaning and servicing
26
5. Electrically connect the appliance.
→Page16
6. Putting the food into the appliance.
13.3 Removing the fittings
If you want to clean the fittings thor-
oughly, remove these from your ap-
pliance.
Removing the shelf
▶ Pull out and remove the shelf.
→Fig.
11
Removing the snack container
with holder
1. Remove the snack container.
2. Remove the shelf with the holder.
3. Slide the holder sideways off the
shelf.
→Fig.
12
Removing door rack
▶ Lift the door rack and remove it.
→Fig.
13
Removing the storage container
1. Pull out the storage container as
far as it will go.
2. Lift the storage container at the
front and remove it .
→Fig.
14
Removing the fruit and vegetable
container
1. Pull out the fruit and vegetable
containers as far as they will go.
2. Lift the fruit and vegetable contain-
ers at the front and remove
them .
Removing the frozen food
container
1. Take out the frozen food container
as far as it will go.
2. Lift the frozen food container at the
front and remove it .
→Fig.
15
Removing the front of the
container
You can remove the front of the fruit
and vegetable container to facilitate
cleaning.
▶ Press in the snap-in hooks on the
side of the container and re-
move the front from the container
in a turning motion .
→Fig.
16
Removing the ice cube maker
1. Pull out the frozen food container
as far as it will go.
2. Loosen the clip on the left side of
the container by pressing it to-
gether and remove the ice cube
maker .
→Fig.
17
13.4 Removing appliance
components
If you want to clean your appliance
thoroughly, you can remove certain
components from your appliance.
Shelf above the fruit and
vegetable container
You can remove the cover of the fruit
and vegetable container in order to
clean it thoroughly.
Removing the shelf above the fruit
and vegetable container
1. Remove the fruit and vegetable
containers. →Page26
2. Remove the storage container.
→Page26
3. Lift the fruit and vegetable con-
tainer covers and remove them
.
→Fig.
18
