en Cleaning and servicing
24
▶ Press in the snap-in hooks on the
side of the container and re-
move the front from the container
in a turning motion .
13.4 Removing appliance
components
If you want to clean your appliance
thoroughly, you can remove certain
components from your appliance.
Removing the shelf above the fruit
and vegetable container
1. Remove the fruit and vegetable
container. →Page23
2. Remove the storage container.
→Page23
3. To release the hooks at the sides,
push the sealing frame upwards
and out.
4. To release the rear hooks, lift up
the sealing frame at the rear
and slide it backwards .
5. Remove the sealing frame.
6. Note:Once you have removed the
sealing frame, you can remove the
shelf above the fruit and vegetable
container, with the door open at an
angle of 90°.
Lift the shelf above the fruit and ve-
getable container at the front and
pull it out slightly.
7. Tilt the shelf approximately 85° up-
wards and swivel it out at the
side .
