en Appliance door
24
Attaching the door
Reattach the oven door by following the same steps in
reverse order.
1. When attaching the oven door, ensure that both
hinges are inserted straight into the opening (Fig. A).
2. The notch on the hinge must engage on both sides
(Fig. B).
3. Fold back both locking
levers (Fig. C). Close the oven door.
:Warning – Risk of injury!
Risk of injury! Do not touch the hinges; the door might
accidentally fall or a hinge might suddenly snap shut.
Call the after-sales service.
Removing and refitting the door panels
The glass panels can be removed from the oven door
to allow more thorough cleaning.
Removing
1. Detach the oven door. To do this, read the section
entitled "Detaching the door". Position it on a cloth with
its handle pointing downwards (Fig. A).
2. Turn the two screws at bottom followed by the two
screws at the top in an anti-clockwise direction (Fig.
b).
3. Remove the complete door base (Fig. C).
Do not wash the removed parts. Only clean the glass
surfaces with a damp, soft cloth and a small amount of
glass cleaner.
:Warning – Risk of injury!
Scratched glass in the appliance door may develop into
a crack. Do not use a glass scraper, sharp or abrasive
cleaning aids or detergents.
Installation
1. Insert the complete door base (Fig. D).
2. First tighten the two screws at the bottom and then
the two screws at the top (Fig. B).
3. Attach the oven door. To do this, see the section
entitled Attaching the door.
Only use the oven once the glass panels have been
correctly fitted.
%
$
&
%
$
&
%
$
