English | 21

Thermal imaging camera GTC 12V-450-13

Recommended battery chargers GAL12…

GAX18…

A) In accordance with standard VDI5585 (average)

B) At an ambient temperature of 20–23°C and an emissivity of ≥0.95, measuring distance: 1m, operating time: >5min, aperture of

150mm, with the worklight and laser switched off

C) Plus use-dependent deviation (e.g. reflection, distance, ambient temperature)

D) Applies to the centre point, all other pixels additionally ±1°C

E) Applies to the centre point, all other pixels additionally ±1%

F) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by condensation is expected.

G) With the worklight switched off and medium display brightness

H) Depending on battery in use

At an ambient temperature of 20–30°C

J) Weight without rechargeable batteries/battery adapter/non-rechargeable batteries

K) with GBA12V2.0Ah or battery adapter

The serial number(20) on the type plate is used to clearly identify your measuring tool.

Measuring Tool Power Supply

The measuring tool can be operated either with a Bosch lith-

ium-ion battery, with commercially available non-re-

chargeable batteries or with commercially available NiMH re-

chargeable batteries.

Operation with Rechargeable Battery

(seefigureA)

u Use only the chargers listed in the technical data. Only

these chargers are matched to the lithium-ion battery of

your measuring tool.

Note: Lithium-ion rechargeable batteries are supplied par-

tially charged according to international transport regula-

tions. To ensure full rechargeable battery capacity, fully

charge the rechargeable battery before using your tool for

the first time.

To insert the charged battery pack(15), slide it into the bat-

tery bay(7) until you feel it engage.

To remove the battery pack(15), press the release

buttons(14) and pull the battery pack out of the battery

bay(7). Do not use force to do this.

Operation with non-rechargeable batteries

(seefigureB)

Using alkali-manganese non-rechargeable batteries or NiMH

rechargeable batteries is recommended for operation of the

measuring tool.

The batteries are inserted into the battery adapter.

u The battery adapter is intended only for use in desig-

nated Bosch measuring tools and must not be used

with power tools.

To insert the batteries, slide the cover(21) of the battery

adapter into the battery bay(7). Place the batteries into the

cover as per the illustration on the cap(23). Slide the cap

over the receptacle until you feel it click into place.

To remove the batteries(22), press the release

buttons(14) on the cap(23) and pull the cap off. Remove

the batteries. To remove the cover(21) from inside the bat-

tery bay, reach into the cover and pull it out of the measuring

tool, applying light pressure to the side wall as you do so.

Always replace all the batteries at the same time. Only use

batteries from the same manufacturer and which have the

same capacity.

u Take the batteries out of the measuring tool when you

are not using it for a prolonged period of time. The bat-

teries can corrode during prolonged storage in the meas-

uring tool.

Recommendations for Optimal Handling of the

Battery

Protect the battery against moisture and water.

Only store the battery within a temperature range of −20 to

50°C. Do not leave the battery in your car in the summer, for

example.

A significantly reduced operating time after charging indic-

ates that the battery has deteriorated and must be replaced.

Follow the instructions on correct disposal.

Operation

u Protect the measuring tool from moisture and direct

sunlight.

u Do not expose the measuring tool to any extreme tem-

peratures or variations in temperature. For example,

do not leave it in a car for extended periods of time. In

case of large variations in temperature, allow the measur-

ing tool to adjust to the ambient temperature before put-

ting it into operation. The precision of the measuring tool

may be compromised if exposed to extreme temperat-

ures or variations in temperature.

u Make sure that the measuring tool is correctly accli-

matised. In case of large variations in temperature, accli-

matisation can take up to 60minutes. This may be the

case, for example, if you store the measuring tool in a cool

car and then perform a measurement in a warm building.

u Avoid hard knocks to the measuring tool or dropping

it. After severe external influences and in the event of ab-

Bosch Power Tools 1 609 92A 9ZG | (14.01.2025)
