English | 9
u Do not force the workpiece into the saw blade. Exert-
ing excessive pressure on the power tool can cause the
saw stand to tip over.
u Ensure that all screws and connecting pieces are
tightly fastened when carrying out work. Loose con-
nections can cause instability and inaccurate sawing.
u Ensure that long and heavy workpieces do not unbal-
ance the saw stand. The free end of long and heavy
workpieces must have something placed underneath it or
be supported.
u When pushing together or pulling apart the saw stand,
do not put your fingers near the points of articulation.
There is a risk of fingers being crushed.
Symbols
The following symbols may provide you with important in-
formation about the use of your saw stand. Please take note
of these symbols and their meaning. Knowing what these
symbols mean will help you to use your saw stand more ef-
fectively and more safely.
Symbols and their meaning
The maximum load bearing capacity
(power tool + workpiece) of the saw
stand is85kg.
Product description and
specifications
Intended Use
The saw stand is intended for holding the following Bosch
benchtop saws (stand 2024.11):
– GTS18V-70 (3601M441..)
– GTS70-216 (3601M306..)
The saw stand and power tool are intended for cutting
boards and profiles.
Product Features
The numbering of the components shown refers to the illus-
trations on the graphics pages at the beginning of the
manual.
(1)
Stop
(2)
Swing latch
(3)
Base frame
(4)
Safety clip
(5)
Saw stand leg
(6)
Fastening set
(7)
Positioning handle for aligning the power tool
(8)
Housing frame of the power tool
Technical Data
Saw stand GTA571
Article number
3 601 M22 8..
Saw stand height mm 557
Max. load bearing capacity
(power tool + workpiece)
kg
85
Weight, approx. kg
6.3
Assembly
Items included
Check to ensure that all the parts listed below have been
supplied before assembling the saw stand:
– Base frame (3)
– Saw stand legs(5) (2 front legs "A" and "B", 2 rear legs
"C" and "D")
– Fastening set (6) consisting of:
Hex socket screw (4 pieces)
lock nuts (4 pieces)
Extra tools required (not included in the delivery):
– Hex key (5 mm)
– Open-end spanner (13 mm)
Assembling the Saw Stand (see figures A1−A2)
– Carefully remove all parts included in the delivery from
their packaging.
– Remove all packing material.
– Press the safety clip(4) and unfold the base frame(3).
– Insert the saw stand legs (5) into the corresponding
square pipes in the base frame (3) until they are aligned
with the assembly holes.
– Screw together the saw stand legs and the base frame us-
ing the nuts and bolts in the fastening set (6).
Securing the Power Tool (see figures B1–B2)
– Place the saw stand on a firm, flat, horizontal surface.
– Centre the power tool on the base frame. Use the
stops(1) and the positioning handles on the power
tool(7) to do this.
– Hook the bracket of the swing latch(2) over the housing
frame(8) and fold down the lever to secure the power
tool.
Operation
Working Advice
Always hold the workpiece firmly in place, especially long,
heavy pieces. Once the workpiece has been cut, the centre
of gravity may be displaced, causing the saw stand to tip
over.
Do not overload the saw stand. Always observe the max-
imum load bearing capacity of the saw stand.
Bosch Power Tools 1 609 92A D6S | (23.06.2025)
