14 | English

LED Capacity

2 × continuous green light 20–40%

1 × continuous green light 5–20%

1 × flashing green light 0–5%

Recommendations for Optimal Handling of the

Battery

Protect the battery against moisture and water.

Only store the battery within a temperature range of −20 to

50°C. Do not leave the battery in your car in the summer, for

example.

Occasionally clean the ventilation slots on the battery using a

soft brush that is clean and dry.

A significantly reduced operating time after charging indic-

ates that the battery has deteriorated and must be replaced.

Follow the instructions on correct disposal.

Assembly

Using the Extension Piece

The 7cm extension piece(10) can be used to increase the

work height of the tool to facilitate ergonomic work for taller

users.

To do this, turn the extension piece(10) onto the drive

spindle(9) and tighten it with the open-ended spanner(11).

Changing the Tool

Mixer paddle with M14 male thread

(9)

(12)

Screw the stirrer paddle(12) into the drive spindle(9). To

do this, hold the drive spindle(9) with an open-ended span-

ner (width across flats22mm), and tighten the stirrer

paddle(12) with a second open-ended spanner (width

across flats22mm or 24mm).

The mixer paddle is disassembled in reverse order.

Operation

Starting Operation

Dusts, e.g. mineral dusts, can be harmful to health. Touch-

ing or breathing in this dust can trigger allergic reactions

and/or cause respiratory illnesses in the user or in people in

the near vicinity.

Materials containing asbestos may only be machined by spe-

cialists.

– Provide good ventilation at the workplace.

– It is advisable to wear a P2 filter class breathing mask.

The regulations on the material being machined that apply in

the country of use must be observed.

Mechanical gear selection

u Operate the gear selector switch only when the power

tool is not in use.

Turn the gear selector switch(7) to the required gear (1 or

2).

You can preselect two speed ranges with the gear selector

switch (7).

First gear:

Low speed range, high torque, max-

imum mixer paddle diameter 160mm

Ideal for working with tough or solid

materials

Second gear:

High speed range, low torque, max-

imum mixer paddle diameter 140mm

Ideal for working with light or liquid

materials

Switching on/off

To start the power tool, first press the lock-off button (1),

then press the on/off switch (3) and keep it pressed.

To switch off the power tool, release the on/off switch (3).

Adjusting the Speed

Adjusting the Speed with the On/Off Switch

You can adjust the speed of the power tool when it is on by

pressing in the on/off switch(3) to varying extents.

Slight pressure on the on/off switch(3) results in a low rota-

tional speed. Increased pressure on the switch causes an in-

crease in speed.

Adjusting the Speed with the Speed Preselection

Thumbwheel

The required speed can also be preselected with the

thumbwheel(5) (even during operation).

The speed needed depends on the mixing material that is to

be mixed and the work conditions.

Soft start

The electronic soft start slowly increases the speed if the on/

off switch(3) is pressed. This prevents the mixing material

that is to be mixed from splashing.

1 609 92A 9J2 | (07.08.2024) Bosch Power Tools
