14 | English

Recommendations for Optimal Handling of the

Battery

Protect the battery against moisture and water.

Only store the battery within a temperature range of −20 to

50°C. Do not leave the battery in your car in the summer, for

example.

Occasionally clean the ventilation slots on the battery using a

soft brush that is clean and dry.

A significantly reduced operating time after charging indic-

ates that the battery has deteriorated and must be replaced.

Follow the instructions on correct disposal.

Assembly

Using the Auxiliary Handle

u Do not operate your power tool without the auxiliary

handle (11).

Before using it for the first time, screw the auxiliary

handle(11) into the handle element(10). There is thread-

locker on the thread to ensure, after a drying time of approx.

12h, that the auxiliary handle(11) does not come loose in

normal operation.

Adjusting the Angle on the Auxiliary Handle

You can swivel the auxiliary handle(11) to any

angle in both directions for a safe work posture

that minimises fatigue.

Loosen the screw(9), turn the auxiliary

handle(11) to the required working position then retighten

the screw(9).

Using the Extension Piece

The 13cm extension piece(8) can be used to increase the

work height of the tool to facilitate ergonomic work for taller

users.

To do this, turn the extension piece(8) onto the drive

spindle(7) and tighten it with the open-ended spanner(12).

Changing the Tool

Mixer paddle with M14 male thread

(7)

(13)

Screw the stirrer paddle(13) into the drive spindle(7). To

do this, hold the drive spindle(7) with an open-ended span-

ner (width across flats22mm), and tighten the stirrer

paddle(13) with a second open-ended spanner (width

across flats22mm or 24mm).

The mixer paddle is disassembled in reverse order.

Operation

Starting Operation

Dusts, e.g. mineral dusts, can be harmful to health. Touch-

ing or breathing in this dust can trigger allergic reactions

and/or cause respiratory illnesses in the user or in people in

the near vicinity.

Materials containing asbestos may only be machined by spe-

cialists.

– Provide good ventilation at the workplace.

– It is advisable to wear a P2 filter class breathing mask.

The regulations on the material being machined that apply in

the country of use must be observed.

Switching on/off

To start the power tool, first slide the lock-off switch (5) up-

wards with your finger, then press and hold the on/off switch

(6).

To switch off the power tool, release the on/off switch (6).

Adjusting the Speed

Adjusting the Speed with the On/Off Switch

You can adjust the speed of the power tool when it is on by

pressing in the on/off switch(6) to varying extents.

Slight pressure on the on/off switch(6) results in a low rota-

tional speed. Increased pressure on the switch causes an in-

crease in speed.

Adjusting the Speed with the Speed Preselection

Thumbwheel

The required speed can also be preselected with the

thumbwheel(4) (even during operation).

The speed needed depends on the mixing material that is to

be mixed and the work conditions.

Soft start

The electronic soft start slowly increases the speed if the on/

off switch(6) is pressed. This prevents the mixing material

that is to be mixed from splashing.

Constant Electronic control

The electronic system of the power tool keeps

the mixer paddle speed constant in the set

range across a wide load range. This guaran-

tees a uniform performance.

Rapid Shut-off (KickBack Control)

The rapid shut-off function (KickBack Con-

trol) gives the user greater control over the

power tool and offers them better protec-

tion than power tools that do not have Kick-

Back Control. The power tool will switch off if it suddenly

and unforeseeably rotates around the axis of rotation.

1 609 92A 9J4 | (07.08.2024) Bosch Power Tools
