English | 15

Product Description and

Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-

structions may result in electric shock, fire

and/or serious injury.

Please observe the illustrations at the beginning of this oper-

ating manual.

Intended Use

The power tool is intended for pressing connection material

onto copper or aluminium cables.

Product Features

The numbering of the product features refers to the diagram

of the power tool on the graphics page.

(1)

Press head release lever

(2)

Press insert

(3)

Press head

(4)

Press insert release button

(5)

Piston rod

(6)

Reset button

(7)

Status indicator

(8)

USB port

(9)

Rechargeable battery

(10)

Battery release button

(11)

Worklight

(12)

Handle (insulated gripping surface)

(13)

On/off button

This accessory is not part of the standard scope of delivery.

Technical Data

Hydraulic cordless pressing tool GPH18V‑60

Article number

3601JP01..

Rated voltage V 18

Max. pressing force kN 60

Max. pressing cross-section mm² 300

Press head turning range ° 340

USB standard for power tool USB 2.0

USB cable for data transfer

(commercially available)

USB Type-C®

Weight

kg 3.0

Recommended ambient tem-

perature during charging

°C 0to +35

Permitted ambient temperature

during operation

°C –10to +50

Permitted ambient temperature

during storage

°C −20to +50

Hydraulic cordless pressing tool GPH18V‑60

Recommended rechargeable

batteries

GBA18V…

ProCORE18V…

Recommended battery chargers GAL18…

GAX18…

GAL36…

A) USBType-C® and USB-C® are trademarks of USB Implementers

Forum.

B) Weight without rechargeable battery

(Weight of rechargeable battery can be found on

http://www.bosch-professional.com)

C) Limited performance at temperatures <0°C

Values can vary depending on the product, scope of application and

environmental conditions. To find out more, visit

www.bosch-professional.com/wac.

Noise/Vibration Information

Noise emission values determined according to

EN62841‑1.

Typically the A-weighted sound pressure level of the product

is less than 70dB(A). The noise level when working can ex-

ceed the declared values.

Wear hearing protection!

Vibration total values a

(triax vector sum) and uncertainty K

determined according toEN62841‑1:

<2.5m/s², K=1.5m/s².

The vibration level and noise emission value given in these

instructions have been measured in accordance with a

standardised measuring procedure and may be used to com-

pare power tools. They may also be used for a preliminary

estimation of vibration and noise emissions.

The stated vibration level and noise emission value repres-

ent the main applications of the power tool. However, if the

power tool is used for other applications, with different ac-

cessories or is poorly maintained, the vibration level and

noise emission value may differ. This may significantly in-

crease the vibration and noise emissions over the total work-

ing period.

To estimate vibration and noise emissions accurately, the

times when the tool is switched off or when it is running but

not actually being used should also be taken into account.

This may significantly reduce vibration and noise emissions

over the total working period.

Implement additional safety measures to protect the oper-

ator from the effects of vibration, such as servicing the

power tool and accessories, keeping their hands warm, and

organising workflows correctly.

Rechargeable battery

Bosch sells some cordless power tools without a re-

chargeable battery. You can tell whether a rechargeable bat-

tery is included with the power tool by looking at the pack-

aging.

Bosch Power Tools 1 609 92A B10 | (22.11.2024)
