English | 13
Battery charge indicator
The green LEDs on the battery charge indicator indicate the
state of charge of the rechargeable battery. For reasons of
safety, it is only possible to query the state of charge when
the cordless worklight is switched off.
Press the button for the battery charge indicator or to
show the state of charge. This is also possible when the re-
chargeable battery is removed.
If no LED lights up after pressing the button for the battery
charge indicator, then the rechargeable battery is defective
and must be replaced.
Battery model GBA 18V...
LED Capacity
3× continuous green light 60–100%
2× continuous green light 30–60%
1× continuous green light 5–30%
1× flashing green light 0–5%
Battery model ProCORE18V...
LED Capacity
5 × continuous green light 80–100%
4 × continuous green light 60–80%
3 × continuous green light 40–60%
2 × continuous green light 20–40%
1 × continuous green light 5–20%
1 × flashing green light 0–5%
Recommendations for Optimal Handling of the
Battery
Protect the battery against moisture and water.
Only store the battery within a temperature range of −20 to
50°C. Do not leave the battery in your car in the summer, for
example.
Occasionally clean the ventilation slots on the battery using a
soft brush that is clean and dry.
A significantly reduced operating time after charging indic-
ates that the battery has deteriorated and must be replaced.
Follow the instructions on correct disposal.
Assembly
Putting the Coin Cell into Operation
(seefigureA)
Remove the separating film between the coin cell(10) and
the coin cell contact when using the tool for the first time.
The cordless worklight is fitted with a coin cell so that it can
be detected by the mobile device even if no battery pack(8)
is inserted.
Unlock the locking mechanism of the battery cover(6) and
fold back the battery cover(5).
Unscrew the screw of the battery compartment cover(12)
and remove the battery compartment cover(11).
Remove the film from the coin cell contact and reattach the
battery compartment cover with the screw.
Operation
Starting Operation
Remove the battery cover (seefigureB)
A very large rechargeable battery will prevent the battery
cover(5) from closing. In this case, the battery cover can be
removed.
Push the two hinges inwards against the spring force. Re-
move the battery cover. There is no IP protection whilst
the battery cover is not in place!
To refit the battery cover, push the two hinges inwards
against the spring force again. Place the battery cover on the
housing. Allow the two hinge pins to engage in the openings
on the housing.
Setting up
Place the cordless worklight on a stable, level surface. Make
sure it is secure.
Hanging up
The notched carrying handle (3) can be used to hang up the
cordless worklight. Make sure it is hung up securely.
Fastening to the tripod
You can use the tripod mount (4) to screw the cordless
worklight onto a tripod.
Tighten the 1/4" screw. Ensure that the tripod has a firm
footing.
Switching on/off and adjusting the brightness
On/off switch Function
Press once Switches on the cordless worklight,
dimmed
Press twice Switches on the cordless worklight,
full brightness
Press three times Switches off the cordless worklight
If the cordless worklight has been switched on in dimmed
mode for approx. five minutes, it will be switched off imme-
diately the next time the button is pressed.
Temperature-dependent overload protection
When the permitted operating temperature is exceeded, the
cordless worklight initially reduces the brightness before
switching itself off if required for protection. Let the cordless
worklight cool down and then switch the cordless worklight
back on.
Bosch Power Tools 1 609 92A 9LT | (16.05.2024)
