18 | English

If the status indicator(3) lights up green at the end of the

punching process, the maximum pressure has been reached

and a full punching operation is detected. If the punching

was not successful, the status indicator lights up red.

Sleep Mode and Restart Protection

For safety reasons, the power tool will be put into sleep

mode in the following cases:

– If it has been more than 5min since the battery was inser-

ted or the tool has not been used for more than 5min

after the last punching process,

– If the on/off button(9) is pressed while the battery is be-

ing inserted (as restart protection).

In this case, briefly press the on/off button(9) once to activ-

ate the power tool. Then start the punching process as usual.

Status indicators

Colour of the status

indicator(3)

Meaning Corrective measure

After inserting the rechargeable battery/waking up from sleep mode:

Green (3s) Power tool ready for use −

Yellow (3s) There are fewer than 1000work cycles re-

maining until the end of the maintenance

interval.

Schedule maintenance with an authorisedBosch

after-sales service centre.

Red (3s) Battery too weak for punching process Charge/change battery

Battery and/or power tool outside the op-

erating temperature range

Allow the battery and the power tool to reach the

correct temperature range

After completion of the punching process/during operation:

Green (3s) Punching successful −

Yellow (continuous) Maintenance interval of 20,000work

cycles exceeded

Send the power tool to an authorisedBosch after-

sales service centre for maintenance.

Red (3s) No complete punching operation, internal

fault of the power tool or power tool out-

side the operating temperature range

1. Restart the punching process

2. Remove and reinsert the rechargeable battery

3. Leave the power tool to adjust to the ambient

temperature

4. If these measures do not help, then contact an

authorised Bosch after-sales service centre.

The specific error messages can also be accessed via the

Bosch Read-Out Software.

Reading Out Work Results with the Bosch Read-

Out Software

The power tool saves data such as pressure and working

time for each work process. To read out this data, you need

the Bosch Read-Out Software, which you can download free

of charge from www.bosch-professional.com. Install the

software and follow the installation instructions. In the soft-

ware, you can also see how many work cycles are still out-

standing until the next maintenance interval.

To transfer log entries, open the flap for the USB port(4)

and connect the power tool with your PC via a USBType-C®

cable. A rechargeable battery must be inserted into the

power tool to access the log entries.

Maintenance and Service

Maintenance and Cleaning

u Before carrying out any work on the power tool (e.g.

maintenance, tool change etc.), remove the battery

from the power tool. There is risk of injury from uninten-

tionally pressing the on/off switch.

u To ensure safe and efficient operation, always keep

the power tool and the ventilation slots clean.

Keep the power tool dry. Only wipe off any dirt using a damp

cloth.

Only store and transport the power tool in the XL‑BOXX.

To ensure that the power tool is operating safely for as long

as possible, the power tool requires maintenance after

20,000work cycles, or after 4years at the latest. Once

20,000work cycles have been exceeded, the status

indicator(3) will light up yellow continuously.

Send the power tool to an authorisedBosch after-sales ser-

vice centre for maintenance.

1 609 92A B0Z | (22.11.2024) Bosch Power Tools
