English | 29

Product Description and

Specifications

Read all safety warnings and all instruc-

tions. Failure to follow the safety warnings and

instructions may result in electric shock, fire

and/or serious injury.

Please observe the illustrations at the beginning of this oper-

ating manual.

Intended Use

The product is intended for sawing wood such as branches,

planks, wooden beams etc., at ground level.

Cuts can be sawed with or across the grain.

This power tool is not suitable for sawing mineral materials

and plasterboard.

This power tool is not intended for felling trees.

This power tool must be operated with two hands whilst in

use.

Delivery Scope

Carefully remove the machine from its packaging and check

if the following parts are complete:

– Pruner saw

– Cover

– Saw chain

– Chain bar

– Chain cover

– Operating instructions

Battery and charger are included in certain versions.

When parts are missing or damaged, please contact your

dealer.

Product Features

The numbering of the product features refers to the diagram

of the power tool on the graphics page.

(1)

Auxiliary hand guard

(2)

Affixed tensioning wheel

(3)

Auxiliary handle/insulated gripping surface

(4)

Lock-off button for On/Off switch

(5)

Rear handle/ insulated gripping surface

(6)

Battery receptacle

(7)

Rear hand guard

(8)

On/Off switch

(9)

Chip ejector

(10)

Cover

(11)

Clamping knob

(12)

Saw chain

(13)

Chain bar

(14)

Battery

a)

(15)

Charger

a)

(16)

Symbol for rotation and cutting direction

(17)

Fastening bolt

(18)

Guide fin for chain bar

(19)

Bolt for chain tension

(20)

Drive sprocket

(21)

Oil filler cap

(22)

Battery release button

(23)

Base plate

(24)

Chain cover

(25)

Oil seal

(26)

Oil reservoir

a)

The accessories illustrated or described are not included as

standard delivery.

Technical Data

Pruner saw GKE 18V-15 GKE 18V-20

Article number

3 601 HD7 0.. 3 601 HD7 1..

Rated voltage V 18 18

Chain speed (no-load) m/s 7.2 7.2

Chain bar length cm 15 20

Compatible chain bar Oregon - 1 619 P18 111

Bosch - 1 619 PS3 141

Oregon - 1 619 P19 527

Bosch - 1 619 PS3 142

Saw chain pitch 3/8" low profile 3/8" low profile

Drive link thickness 1.1 (0.043") 1.1 (0.043")

Amount of drive links 28 33

Max. cutting diameter cm 13 18

Toolless chain tensioning (SDS) ● ●

Automatic chain oiler ● ●

Nose sprocket ● ●
