26 | English

u Use personal protective equipment if there is a

risk that you may touch live parts in the system

in which the current is to be measured.

Symbols

Symbols and their meaning

Device with double or reinforced insula-

tion

Caution: Risk of electric shock!

Use in the vicinity of non-insulated dan-

gerous live conductors permitted

Connection for earth

Product Description and

Specifications

Please unfold the fold-out page with the diagram of

the measuring tool and leave it open while reading

the instruction manual.

Intended Use

The measuring tool is intended for measuring altern-

ating current, voltage (including with a lower input

impedance [LoZ]) and resistance, and for continuity

testing. It can also be used for measuring the fre-

quency of alternating voltage and for non-contact

voltage testing of alternating voltages between 24

and 1000V.

The measuring tool may only be used in circuits with

a rated voltage≤1000VDC/AC.

The measuring tool is suitable for indoor use.

Product Features

The numbering of the product features refers to the

representation of the measuring tool in the images.

(1)

Display

(2)

Rotation switch (for selecting the measuring

function)

(3)

Tab for fixing the magnetic hanger

(4)

Torch

(5)

Test probe for non-contact voltage testing

(6)

Measuring fork

(7)

Arrows for cable positioning

(8) Hold button (holding of the measured value

on the display or sound on/off)

(9)

Torch on/off button

(10) Sel button (second assignment of measur-

ing function)

(11) (+) input terminal (input terminal for meas-

uring voltage, continuity and resistance)

(12) COM input terminal (earth connection (re-

turn conductor) for measuring voltage, con-

tinuity and resistance)

(13)

Red test lead

1 609 92A B0H | (21.01.2025) Bosch Power Tools
