20 | English

Product Description and

Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-

structions may result in electric shock, fire

and/or serious injury.

Please observe the illustrations at the beginning of this oper-

ating manual.

Intended Use

The power tool is intended for dry cutting in metal materials

with bonded cutting discs or diamond cutting discs.

The power tool is intended for wet cutting in concrete, ma-

sonry and stone solely with the use of diamond cutting discs.

Product Features

The numbering of the product features refers to the diagram

of the power tool on the graphics page.

(1)

On/off switch

(2)

Lock-off function for on/off switch

(3)

Auxiliary handle

(4)

Handle (insulated gripping surface)

(5)

Protective guard

(6)

Protective guard knob

(7)

Adjusting lever for protective guard

(8)

Direction of rotation arrow

(9)

Clamping bolt with washer

(10)

Clamping flange

(11)

Mounting flange

(12)

Drive spindle

(13)

Spindle locking lever

(14)

Battery compartment cover

(15)

Release button for battery compartment cover

(16)

Valve for water connection

(17)

Connector for water connection

(18)

Adapter for water connection

(19)

Worklight

(20)

Battery charge indicator

(21)

Power tool status indicator

(22)

Rechargeable battery

(23)

Battery release button

(24)

Ring spanner

(25)

Diamond cutting disc

This accessory is not part of the standard scope of delivery.

Technical Data

Cut-off saw GCS 18V-230

Article number

3601CB00..

Cut-off saw GCS 18V-230

Rated voltage V= 18

No-load speed

min

–1

6200

Max. diameter of the cut-

ting disc/diamond cutting

disc

mm 230

Locating bore mm 22.2

Max. cutting disc thick-

ness (metal)

mm 1.9

Max. cutting disc thick-

ness (diamond)

mm 2.6

Max. permissible water

pressure

bar 6.2

Weight

kg 6.4 (8.0Ah)–

6.8 (12.0Ah)

Recommended ambient

temperature during char-

ging

°C 0to+35

Permitted ambient tem-

perature during opera-

tion

and during storage

°C –20to+50

Compatible rechargeable

batteries

GBA18V...

ProCORE18V...

Recommended re-

chargeable batteries for

maximum performance

ProCORE18V...

≥8.0Ah

Recommended battery

chargers

GAL18...

GAX18...

GAL36...

Measured at 20–25°C with rechargeable batteryProCORE18V

12.0Ah

B) Straight disc shape

C) Depending on battery in use

D) Limited performance at temperatures <0°C

Values can vary depending on the product, scope of application and

environmental conditions. To find out more, visit

www.bosch-professional.com/wac.

Noise/Vibration Information

Noise emission values determined according

toEN60745-2-22.

Typically, the A-weighted noise level of the power tool is:

Sound pressure level 95dB(A); sound power

level106dB(A). Uncertainty K=3dB.

Wear hearing protection!

Vibration total values a

(triax vector sum) and uncertaintyK

determined according to EN60745-2-22:

Cutting: a

< 2.5m/s

, K=1.5m/s

The vibration level given in these instructions has been

measured in accordance with a standardised measuring pro-

cedure and may be used to compare power tools. It can also

be used for a preliminary estimation of exposure to vibra-

tion.

1 609 92A 3AM | (15.11.2024) Bosch Power Tools
