40 | English

Point and line laser GCL 12V-50-22 CG

Recommended battery chargers GAL 12…

GAX 18…

A) The working range may be reduced by unfavourable environmental conditions (e.g. direct sun-

light).

B) The values stated presuppose normal to favourable environmental conditions (e.g. no vibration,

no fog, no smoke, no direct sunlight). Extreme fluctuations in temperature can cause deviations

in accuracy.

C) An additional deviation of ±0.1mm/m must be taken into account when at maximum self-level-

ling range.

D) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by

condensation is expected.

E) Shorter operating times when operated with Bluetooth®

F) When using Bluetooth® Low Energy devices, it may not be possible to establish a connection de-

pending on the model and operating system. Bluetooth® devices must support the SPP profile.

G) The signal range may vary greatly depending on external conditions, including the receiving

device used. The Bluetooth® range may be significantly weaker inside closed rooms and through

metallic barriers (e.g. walls, shelving units, cases, etc.).

H) Weight without rechargeable batteries/battery adapter/non-rechargeable batteries

I) The lithium-ion battery pack and the battery adapter are excluded from the protection rating.

The serial number (9) on the type plate is used to clearly identify your measuring tool.

Measuring Tool Power Supply

The measuring tool can be operated either with conventional non-rechargeable batteries

or with a Bosch lithium-ion battery.

Operation with Non-Rechargeable Batteries

It is recommended that you use alkaline manganese batteries to operate the measuring

tool.

The batteries are inserted into the battery adapter.

u The battery adapter is intended only for use in designated Bosch measuring

tools and must not be used with power tools.

To insert the batteries, slide the cover (14) of the battery adapter into the battery bay

(15). Place the batteries into the cover as per the illustration on the sealing cap (11).

Slide the sealing cap over the cover until you feel it click into place.

To remove the batteries(13), press the release buttons(12) on the cap(11) and pull

the cap off. Remove the batteries. To remove the cover(14) from inside the battery bay,

1 609 92A 9B1 | (14.08.2024) Bosch Power Tools
