Je bekijkt pagina 37 van 717

English | 37

(10)

Rechargeable battery

a)

(11)

Battery adapter cap

(12)

Rechargeable battery/battery adapter release button

(13)

Batteries

a)

(14)

Battery adapter cover

(15)

Battery bay

(16)

Fastening slot

a)

(17)

Guide rail

a)

(18)

Rotating mount (RM20)

a)

(19)

Fine adjustment screw of the rotating mount

a)

(20)

Magnet

a)

(21)

Ceiling clip (DK20)

a)

(22)

Universal holder

a)

(23)

Holder (LB10)

a)

(24)

Laser target plate

a)

(25)

Laser viewing glasses

a)

(26)

Laser receiver

a)

(27)

Tripod

a)

(28)

Telescopic rod

a)

(29)

Battery adapter

(30)

Protective bag

a)

(31)

Case

a)

This accessory is not part of the standard scope of delivery.

Technical Data

Point and line laser GCL 12V-50-22 CG

Article number

3601K66S..

Working range

A)

– Standard laser lines 25m

– Laser lines with laser receiver 5–50m

– Laser points 10m
