38 en | Configuration

FLEXIDOME panoramic 5100i | FLEXIDOME

panoramic 5100i IR

2024-11 | V03 | F.01U.385.628

User manual

Bosch Security Systems B.V.

Line Out

(Only applicable to FLEXIDOME panoramic 5100i IR)

Adjust the audio level with the slider(s). Adjust so that the indicator does not go into the

red zone.

Recording format

Select a format for audio recording. The default value is 48 kbps. You can select 80 kbps,

G.711 or L16 depending on the required audio quality or sampling rate.

AAC audio technology is licensed by Fraunhofer IIS.

(http://www.iis.fraunhofer.de/amm/)

Send audio

(Only applicable to FLEXIDOME panoramic 5100i IR)

Audio can be sent via the Send audio button if the unit supports audio. The button activates

the audio backchannel connection.

1. Click and hold the Send audio button to send an audio signal to the unit.

2. Release the button to stop sending audio.

You must have a speaker or similar connected to the line out of the camera in order to send

the audio.

Click Set to apply the changes.

5.4.14 Pixel Counter

The number of horizontal and vertical pixels covered by the highlighted area is displayed

below the picture. With these values you can check whether the requirements for specific

functions, for example, identification tasks, are fulfilled.

1. Click Freeze to freeze the camera image if the object that you want to measure is

moving.

2. To reposition a zone, place the cursor over the zone, hold down the mouse button and

drag into position.

3. To change the shape of a zone, place the cursor over the edge of the zone, hold down

the mouse button and drag the edge of the zone to the required position.

5.5 Recording

Images can be recorded to an appropriately configured iSCSI system or, for devices with a

MicroSD slot, locally to a MicroSD card.

SD cards are the ideal solution for shorter storage times and temporary recordings. They

can be used for local alarm recording or to improve the overall reliability of video recording.

For long-term authoritative images use an appropriately sized iSCSI system.

Two recording tracks are available (Recording 1 and Recording 2). The encoder streams and

profiles can be selected for each of these tracks for both standard and alarm recordings.

Ten recording profiles are available where these recording tracks can be defined differently.

These profiles are then used for building schedules.

A Video Recording Manager (VRM) can control all recording when accessing an iSCSI

system. The VRM is an external program for configuring recording tasks for video servers.
