The flatter the tilt angle is set, the less accurate the estimate of object sizes and speeds will
be. The settings must be between 0° and 90°. Estimates are no longer possible when you have
reached 0°.
Roll angle [°]
Enter the roll angle if the value is not determined by the camera.
The roll angle describes the angle between the roll axis and the horizontal plane. The angle
can deviate from the horizontal by up to 45°.
Height [m]
Enter the height in meters of the position of the camera.
The height describes the vertical distance from the camera to the ground plane of the
captured image. Typically the elevation of the mounted camera above the ground.
Focal length
Enter the focal length in meters of the position of the camera if the value is not determined by
the camera.
The focal length is determined by the lens. The shorter the focal length, the wider the field of
view. The longer the focal length, the narrower the field of view and the higher the
magnification.
AutoSet
Click to automatically set the camera parameters, for example, Tilt angle [°], Roll angle
[°],Height [m] and Focal length.
The AutoSet functionality is available on DINION and FLEXIDOME cameras.
Using the AutoSet functionality, the following calibration information are read out
automatically:
– The focal length of inbuilt fix or varifocal lenses and the motor position of varifocal
lenses.
– The tilt and roll angles of cameras on CPP7 and later platforms due to the integrated 6-
axis gyro sensor.
The camera continually updates the values and with each update the values can slightly differ
without affecting the calibration result.
Notice!
Cameras on CPP6 or earlier platforms do not have an integrated gyro sensor and cannot
automatically determine tilt and roll angles. And when in addition the camera also has no
inbuilt lens, the AutoSet functionality is not available. The AutoSet functionality is also not
available for FLEXIDOME IP panoramic cameras.
Sketch
Click to improve the automatic calibration. The Sketch Calibration window is displayed.
The Sketch functionality offers an additional, half-automatic calibration method. This
calibration method allows you to describe the perspective in the camera’s field of view by
drawing vertical lines, ground lines, and ground angles in the camera image and entering the
correct size and angle. Use the Sketch functionality if the result of the automatic calibration is
not sufficient.
You can also combine this manual calibration with the values for roll angle, tilt angle, height
and focal length calculated by the camera or entered manually.
Notice!
The Sketch functionality is not available for FLEXIDOME IP panoramic cameras.
