Configuration - Camera
Camera - Installer menu
Base frame rate
Select the base frame rate for the camera.
Note:
Shutter times and frame rates, and the analog output (if present) are affected by this value.
Video format
Select the encoding mode, H.264 or H.265 .
Camera LED
(only available on some cameras)
Disable the Camera LED on the camera to switch it off.
Image rotation
(only available on some cameras)
The integrated gyro/accelerometer sensor detects the optimal image orientation and allows
the user to select it by clicking Use proposed rotation.
Select the required angle (0°, 90°, 180° or 270°) to output the correct image orientation.
Mirror image
(only available on some cameras)
Select On to output a mirror image of the camera picture.
Button "MENU"
Select Disabled to prevent access to the install wizard via the menu button on the camera
itself.
Analog output
Select an aspect ratio format to activate the analog output of the camera.
Reboot device
Click Reboot to restart the camera.
Factory defaults
Click Defaults to restore the factory defaults for the camera. A confirmation screen appears.
Allow several seconds for the camera to optimize the picture after a reset.
Lens wizard
Click Lens Wizard... to open a separate window which can be used to focus the camera lens
(not for all cameras).
This page enables you to focus the lens on a particular area.
In the preview window, use the mouse to change the size and position of the shaded box that
defines the focus area. (Check the box below the preview window to show only the defined
area in the main window.)
Default
(only for cameras with motorized focus adjustment)
Click Default to set the lens to its default position.
6
6.1
6.1.1
6.1.2
6.1.3
6.1.4
6.1.5
6.1.6
6.1.7
6.1.8
6.1.9
6.1.10
Camera Browser Interface Configuration - Camera | en 27
Bosch Security Systems Software manual 2017.09 | v1.0 |
