Operation via the browser
Browser Live page
After the connection is established, the Live page is initially displayed. It shows the live video
image on the right of the browser window. Depending on the configuration, various text
overlays may be visible on the live video image.
Other information may also be shown next to the live video image. The items shown depend
on the settings on the 'Live' functions page.
Connection >> Stream
To view a live stream:
1. On the left side of the browser, expand the Connection group if necessary.
2. Click the Stream drop-down arrow to see the options.
3. Select the stream you wish to view.
When the Stream 2 encoder stream is set for Region of Interest (ROI), the ROI control panel is
activated.
Refer to Encoder Streams for more information on setting up Stream 2. (If dual ROI is
available, open the camera in a second browser window to set up the ROI on Stream 2.)
ROI / PTZ >> Image orientation
(only available on some cameras)
With ROI, you can select an area which can then be saved in a pre-position. You can
manipulate the image with the controls on the left side of the browser or with the mouse.
– Place the cursor on the image; you see an arrow on the image.
– Click an arrow to orientate the image.
– Use the scroll wheel to zoom in and out.
Pre-positions
(only available on some cameras)
Six pre-position files can be defined for views generated by the region of interest (ROI)
controls.
1. On the left side of the browser, expand the Pre-positions group if necessary.
2. Use the ROI controls to define a particular view.
3. To store this view, click the
icon of one of the six pre-position buttons.
– If a pre-position is already stored, a dialog box displays a message. Click OK to
overwrite or Cancel to cancel the operation
4. To recall a stored pre-position, click a pre-position button.
Digital I/O
(only for cameras with alarm connections)
Depending on the configuration of the unit, the alarm input and the output are displayed next
to the image. Expand the Digital I/O group if necessary.
The alarm symbol is for information and indicates the status of an alarm input:
– The symbol lights when the input alarm is active.
The alarm output allows the operation of an external device (for example, a light or a door
opener).
– To activate the output, click the checkmark symbol.
3
3.1
3.1.1
3.1.2
3.1.3
3.1.4
12 en | Operation via the browser Camera Browser Interface
2017.09 | v1.0 | Software manual Bosch Security Systems
