Cordless Impact
Driver
EasyImpactDrive 12
– Setting 1 rpm 0 - 1400
– Setting 2 rpm 0 - 2800
Impact rate
– Setting 1 rpm 0 - 2400
– Setting 2 rpm 0 - 3300
Maximum torque, hard
screwdriving applica-
tion according to
ISO5393
Nm 100
Machine screw dia-
meter
mm M4–M12
Max. screw diameter mm 6
Tool holder ¼"internal hexagon
Weight according to
EPTA-Procedure
01:2014
kg 1.0
Permitted ambient temperature
– While charging °C 0 to +45
– During operation and
storage
°C -20 to +50
Recommended batter-
ies
PBA 10.8V ...
PBA 12V ...
Recommended char-
gers
(Limited performance
at temperatures <0°C)
AL 11.. CV
GAL 1220
Noise/vibration information
Noise emission values determined according to EN
62841-2-2.
Typically the A-weighted noise level of the power tool is:
88dB(A); sound power level 99dB(A). Uncertainty K =
3dB.
Wear hearing protection!
Total vibration values a
h
(triax vector sum) and uncertainty K
determined according to EN 62841-2-2:
Impact tightening of fasteners of the maximum capacity of
the tool: a
h
<9,5m/s
2
, K=1,5m/s
2
The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure detailed in EN 62841
and may be used to compare power tools. They may also be
used for a preliminary estimation of vibration and noise
emissions.
The given vibration level and noise emission value represent
the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping the hands warm,
and organising workflows correctly.
Assembly
Removing the battery (see figureA)
u Use only the chargers listed on the accessories page.
Only these chargers are matched to the lithium-ion bat-
tery of your power tool.
Note: The battery is supplied partially charged. To ensure
full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the Electronic Cell Protection (ECP). A protective circuit
switches the cordless dust extractor off when the battery is
drained.
u Do not continue to press the On/Off switch after the
power tool has automatically switched off. The battery
can be damaged.
To remove the battery (5), press the release button (4) and
pull the battery downwards out of the power tool. Do not
use force to do this.
Follow the instructions on correct disposal.
Changing the Tool
u Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage. There is risk of injury
from unintentionally pressing the on/off switch.
Inserting the application tool (seefigureB)
Pull the locking sleeve (2) forward, guide the application tool
(1) into the tool holder up to the stop and release the locking
sleeve (2) to lock the application tool.
Screwdriver bits (12) can be inserted using a universal bit
holder with ball catch (11).
Removing
Pull the locking sleeve (2) forward and remove the applica-
tion tool.
English | 13
Bosch Power Tools 1 609 92A 480 | (04.07.2018)
