Connecting the feeder cable
Attention
If the power supply cable is damaged, it must be replaced only by
an authorised service agent in order to avoid a hazard.
To connect the feeder cable to the cooker it is necessary to:
* Remove the two screws that hold shield “A” behind the cooker.
* Open completely the cable clamp “D”.
* Position the U bolts onto terminal block “B“ (fig. 9.1) according to the
diagram in figs. 9.2, 9.3
* Insert the feeder cable into the cable clamp “D”. The supply cable
must be of a suitable size (see the section “Feeder cable section”).
* Connect the phase and earth cables to terminal “B” according
figures 9.2, 9.3
* Pull the feeder cable and block it with the cable clamp “D”.
* Re-mount shield “A”.
N.B.
The earth conductor must be left about 3 cm longer than the
others.
ENBoretti Milano / User guide - Installation advice
