Cleaning and maintenance
EN
bora.com 41
1
2
3
Fig.7.1
Removing the grease filter components
[1]
Cover flap
[2]
Grease filter
[3]
Filter tray
7.2.2
Fitting the cover flap, grease filter
and filter tray
u
Insert the filter tray in the opening on the extractor.
u
Insert the grease filter into the opening in the extractor.
u
Ensure that the grease filter sits correctly in the gap in the housing.
u
Lay the cover flap on its side next to the extractor opening.
u
Allow the cover flap to slide diagonally into the holder.
u
Press the ends of the cover flap lightly from above until you hear
them click into place.
u
Make sure that the cover flap has been fitted correctly.
T
If the cover flap is not properly installed in its locking mechanism,
it will not close fully.
T
If the grease filter or cover flap has not been properly fitted, the
error message ‘E012’, ‘E013’ or ‘FF out’ appears on the control
knob’s display (see"8Troubleshooting").
Fig.7.2
Fitting the components
1 2 3
Fig.7.3
Fitting the cover flap
[1]
Extractor opening
[2]
Holder
[3]
Cover flap
7.2.3
Removing the maintenance tray
The maintenance tray cannot be removed in the following installation
situations:
T
single installation
T
second adjacent extractor
T
adjacent wok cooktop
To remove the maintenance tray, the grease filter and filter tray must
be removed first.
u
Turn the two levers of the lock outwards 90° to unlock the
maintenance tray.
u
Lift the maintenance tray out of the cooktop extractor.
12
Fig.7.4
Removing the maintenance tray
[1]
Maintenance tray
[2]
Lock
7.2.4
Installing the maintenance tray
u
Slide the maintenance tray into the cooktop extractor.
