Functions and operation
EN
bora.com 29
If both cooking zones are already in use when the bridging function is
activated, the lower of the two power levels will be adopted for both
cooking zones.
If a timer is running when the bridging function is activated, this is
adopted. If 2 timers are running, the shorter one is used for the
bridging function.
Activating the bridging function
u
Touch command on both control knobs at the same time.
T
An acoustic signal can be heard and the bridging function is
activated.
T
The power level and both cooking zone indicators are shown on
both control knobs.
Fig.5.26
Activating the bridging function
Deactivating the bridging function
u
Set the power level to 0.
or
u
Touch command on both control knobs at the same time.
T
An acoustic signal can be heard and the bridging function is
deactivated.
T
The current power levels are retained.
T
Each cooking zone then goes back to being operated separately.
5.5.7
Pause function
With the pause function all cooking zones can be quickly and easily
deactivated temporarily. When the function is cancelled, operation
resumes at the original settings. The cooking session can be paused
for a maximum of 10 minutes. Once 10 minutes have lapsed, the
cooking session is automatically ended.
During the pause, fan function is not interrupted. Active
bridging and short-time timer functions remain active. Active
cooking zone timers are stopped.
Activating the pause function
u
Double tap the cooktop extractor control knob
T
appears in the cooktop extractor control knob display fading in
and out.
T
The cooktop control knob displays are dimmed.
Fig.5.27
Activating the pause function
Deactivating the pause function
u
Double tap the cooktop extractor control knob
T
The cooktop control knob displays light up again.
T
Paused cooking zone timers resume their countdown.
Fig.5.28
Deactivating the pause function
5.5.8
Pan size recognition
On induction cooktops the cooking zone recognises the size of the
cookware automatically and only targets the energy at that area. It
also recognises cookware that is unsuitable or too small, or if there is
no cookware present. A cooking zone is not working if / are
alternated in the display. This happens if
T
it is switched on without cookware or with unsuitable cookware;
T
the base diameter of the cookware is too small;
T
the cookware is removed from a switched-on cooking zone.
If no pot is recognised 10 minutes after setting a power level, the
cooking zone will switch off automatically.
5.6
Cooktop function menu
Every appliance offers different additional functions. These can be
selected and activated via a function menu. Only the functions
available for each type of appliance are shown in the corresponding
function menu.
Menu item Designation
Heat retention function (3 levels)
Cooking zone timer
Automatic heat up function
Tab.5.5
Function menu on induction cooktops
