Functions and operation
EN
24 bora.com
Fig.5.12
Turning the knob ring clockwise
Fig.5.13
Turning the knob ring anticlockwise
T
When set to between 0 and 10 minutes, the time reduces/
increases in 30-second increments when the control knob is
turned.
T
When set to between 10 and 20 minutes, the time reduces/
increases in 1-minute increments when the control knob is turned.
Otherwise, it increases/decreases in 5-minute increments.
T
After confirming with a touch command, an acoustic signal is
heard, the short-time timer is activated and the set time starts to
count down.
T
The current power level and remaining time are shown alternately
in the control knob display.
T
The current time remaining is shown to the minute when more than
10 minutes remain, to 30 second increments when less than 10
minutes remain, and to the second when only 2 minutes remain.
Time lapsed
When the set time has elapsed, an acoustic signal sounds for 1
minute and the timer displayed on the control knob counts down as a
negative.
The flashing and the acoustic signal can be stopped by pressing the
touch surface.
Switching off the short-time timer early
Fig.5.14
Switching off the short-time timer early
T
The short-time timer is deactivated early and an acoustic signal is
heard.
5.4.3
Automatic extractor function
The extractor power level automatically adjusts itself depending on
the current cooktop settings. No manual adjustment of the fan
controls is necessary but it is possible.
Cooktop power levels Temperature PKT3 Cooktop extractor
power level
Heat retention level 1 - 2
Heat retention level 2 - 4
Heat retention level 3 - 7
1 70–80 2
2 90–160 3
3 170 4
4 180 5
5 190 6
6 200 7
7 210 8
8 220 9
9 230 9
P 240/250 P
Tab.5.4
Cooking levels and assigned extractor power level when the
automatic extractor function is active
If the power level of a cooking zone is changed, the automatic
extractor function automatically adjusts the extractor power level
after a time delay of...
T
...10 seconds (cooktops PKFI3, PKI3, PKIW3).
T
...20 seconds (cooktops PKC3, PKCB3, PKCH3, PKT3)
Activating the automatic extractor function
Fig.5.15
Activating the automatic extractor function
T
The automatic extractor function is activated.
T
is shown in the control knob displayed.
If the power level is changed on one of the connected cooktops, the
extractor power level is automatically adjusted after a slight delay.
If all connected cooking zones are switched off or paused, the
automatic after-run function will start after a slight delay.
The automatic extractor function is permanently activated and
remains active each time the system is started up until it is
deactivated.
