Functions and operation
EN
22 bora.com
4
Functions and
operation
u
Observe all safety and warning information (see"2Safety").
The cooktop extractor is the central component and contains
all of the electronics for operating the entire system. It is not
possible to operate the system or individual components
without a cooktop extractor.
The cooktop extractor must only be operated when the
grease filter components are installed.
4.1
General and specific operating
instructions
The cooktop extractor and cooktops are operated via a central
operating panel. The operating panel is fitted with electronic sensor
buttons and display panels. The sensor buttons respond to finger
contact. You operate the appliance by tapping the corresponding
sensor button with your finger (touch control) or by a swipe of your
finger (slider operation).
Not all symbols are displayed on all appliances. Functions and
indicators are authorised corresponding to the installed
appliances.
4.1.1
Special operating instructions for
the Tepan stainless steel grill
Initial operation:
u
Heat the griddle to 220°C for approx. 25 minutes before using it
for the first time (= power level 8 for both grilling zones).
T
Bothersome odours may be emitted during this process.
Operating instructions:
u
Clean the grill surface before using the appliance for the first time
(Cleaning and maintenance).
u
Preheat the grilling zone for 5 minutes before it is used each time.
T
During heating or cooling the griddle may make some noise. This is
a normal occurrence.
T
A fan is built in to the Tepan stainless steel grill for cooling,
guaranteeing a long service life for the electronic components and
rapid cooling of the grill surface. Different measures have been
taken to keep noise to a minimum, but it cannot be completely
avoided.
T
During use, the griddle may show signs of curvature.
T
During grilling or heating on a high power level, the griddle may
adopt a light brown colour.
4.1.2
Special operating instructions for
the gas cooktop
Minimum requirement for operating the gas cooktop: System
software 03.00 (or higher).
Clean the cooking zone before using the cooktop for the first
time (Cleaning and maintenance).
When operating the cooktop for the first time or after a
prolonged period without use or when the liquid gas bottles
have been changed, it is possible that the burner may not
ignite. This may be due to air in the gas pipe or the electronic
gas regulator may need recalibrating. Follow the initial
operation instructions (see “Installation instructions”).
In the case of the gas cooktop, due to the use of enamelled
cast iron parts, slight colour variations and irregularities are
common. Furthermore, flash rust may appear at the support
points, which can be easily removed with a damp cloth. These
spots are normal and are not considered an impairment.
As a result of use, some of the components of the gas
cooktop can become discoloured. This discolouration is
normal and does not have a negative effect on the gas flame
or the functioning of the cooktop.
When using the gas burner, you may hear gas escaping from
it. The burner flame turns orange as a result of prolonged
operation and/or impurities on the burner and in the ambient
air (dust). These properties are normal and can occur
independently of one another.
In the event of smoke or fire while operating the gas cooktop,
turn off the gas supply and switch off the appliance at the wall
socket.
If you smell gas or have problems with the gas installation,
switch off the gas supply. Open the window and ensure good
ventilation.
Operating instructions:
The use of a gas cooktop results in the formation of heat and
moisture in the area where it is installed. Intensive use of the
appliance for a long time may require additional ventilation, e.g.
opening a window or more effective ventilation, e.g. operation of the
mechanical ventilation device at a higher power level.
u
Ensure sufficient ventilation.
u
Keep natural ventilation openings open.
u
Use a mechanical ventilation device if possible.
u
Do not put cookware with an uneven base on the pan support.
u
Never heat empty cookware.
u
Always place the cookware on the pan support provided. Cookware
must not be placed directly on the burner.
u
Do not use roasters, pans or stone grills that are so large that they
cover several burners. The resulting heat accumulation can
damage the cooktop.
u
Ensure that the burner parts and pan supports are positioned
correctly.
u
Do not switch the gas cooktop on until all burner parts are
correctly assembled.
u
Ensure that the burner flame does not protrude from under the
base of the cookware and rise up the outside of the pot.
u
Do not keep any highly flammable objects near the cooktop.
Only use cookware with a diameter that is within the given
dimensions. If the diameter is too large, the hot gases and
flames flowing outwards from under the base may damage
the worktop or any non-heat-resistant surfaces, e.g. walls
