Appliance description
EN
bora.com 11
3
Appliance
description
u
Observe all safety and warning information (see"2Safety").
3.1
Cooktop extractor
The cooktop extractor is the central component and contains
all of the electronics for operating the entire system. It is not
possible to operate the system or individual components
without a cooktop extractor.
3.1.1
Model description
Model Long description
CKA2 Classic cooktop extractor
flexible system with separate control unit, can be
combined with the Classic cooktops and other Universal
components
CKA2AB Classic cooktop extractor All Black
flexible system with separate control unit, can be
combined with the Classic cooktops and other Universal
components
Tab.3.1
Model description
3.1.2
Structure
1
2
3
4
Fig.3.1
Classic cooktop extractor
[1]
Air inlet nozzle
[2]
Grease filter unit
[3]
Cooktop extractor
[4]
Control unit
3.1.3
How it works
Depending on the model you purchased, the cooktop extractor can
be operated as an exhaust air or a recirculating air version.
Exhaust air
The air suctioned away is purified by the grease filter and expelled
into the open air via a duct system.
The exhaust air must not be expelled into:
T
a smoke or exhaust gas flue that is in operation
T
a shaft used for the aeration of rooms where fireplaces are
installed.
If the exhaust air is to be directed into a smoke or exhaust gas flue
that is not in use, the installation must be checked and approved by
the responsible heating engineer.
If the cooktop extractor is used in an exhaust air system, the
extractor power is automatically increased for the first 20
seconds when set on a lower power level (wall sleeve
function).
Recirculation
The air suctioned away is purified by the grease filter and an activated
charcoal filter and fed back into the room in which the appliance is
installed.
To prevent odours in recirculation mode, an odour filter must be
used. For health and hygiene reasons, the activated charcoal filter
must be replaced at the recommended intervals (Cleaning and
maintenance).
In recirculation mode, ensure sufficient ventilation and
aeration to expel humidity.
If the cooktop extractor is used in a recirculating air system,
when a power level is set the operating time is automatically
deducted from the recirculation filter service life. The
remaining filter service life can be seen in the menu.
3.1.4
Overview of features and functions
Features CKA2 / CKA2AB
Automatic fan detection 3
Electronic power adjustment 3
Interface communication 3
Compact grease filter unit 3
Functions
Automatic after-run 3
Power setting 3
Automatic extractor function 3
Filter service indicator (recirculation mode) 3
Safety features
Control lock 3
Safety shut-down 3
Active error monitoring 3
Tab.3.2
Overview of features and functions
