15
• if the appliance is supplied without a cable, use a type H05RR-F or H05V2V2-F cable of suitable gauge (see Fig. 2 – page 17);
The installer is responsible for making the electrical connection correctly and for compliance with safety regulations. The electrical
connection diagrams are provided in Fig. 2 – page 17.
IMPORTANT WARNING:
The manufacturer cannot be held responsible for any damage caused by failure to comply with the instructions provided and the
relevant regulations and standards.
7. GENERAL PRECAUTIONS
7.1. Oven Accessories
The accessories provided in the oven are:
1. The shelf, which supports the pans for cooking confectionery or roasts, or on which meat for grilling is placed directly.
2. The drip pan under the grill is used to collect juices, which drip from the food that is cooked directly on the grill. The drip pan can
also be used for cooking.
7.2. “Pull-Out Oven Runners” Kit
Some versions of the appliance are fi tted with telescopic runners.
They are extremely convenient when cooking, since they allow shelves to be pulled right out, and stopped in the fully extracted position.
This convenient aid allows foods to be checked with no risk of burns, and ensures more thorough cleaning.
The oven can be fi tted with a “Pull-Out Runner” kit on request.
This optional can be ordered from your dealer.
8. ASSISTANCE – DIAGNOSTIC MODE
When the oven is in the Power-up state (fl ashing clock), the test mode can be activated by simultaneously pressing the TEMPER+
and the EDITION+ keys for 5 seconds.
8.1. Phase 1 – Display Board
All the display segments are all turned on. If a key is pressed, the code associated to this key is temporarily displayed, to then return
to display all the segments. The automatic repetition is activated for keys equipped with this function.
If a key is not pressed for approx. 10 seconds, the oven passes to the next phase.
8.2. Phase 2 – Power Board
The clock display shows “8888” with the symbols fl ashing, while the display shows the temperature read by the oven probe. The
symbol is off. By pressing a key, the associated code is shown on the clock display.
The Double Cut relay is kept closed, and all the other relays are cyclically activated, one at a time. Once the last relay is reached, the
cycle starts over.
If a key is not pressed for approx. 10 seconds, the diagnostic phase is terminated and the oven returns to the Power-up phase.
Instructions
GB
6.4 Connecting to the electrical mains
For direct connection to the mains, a mains cut-off device with a contact breaking gap that ensures complete disconnection in category
lll overvoltage conditions must be provided, in accordance with the installation rules.
WARNING: The plug must be reachable when the appliance is installed.
Useful information for the installation engineer:
• the green-yellow coloured wire must be used to make the earth connection;
• the blue wire for the neutral;
• the brown wire for the live connection;
• the cable must not touch hot surfaces with a temperature over 75°C;
• if the cable is replaced, the new one must be of H05RR-F or H05V2V2-F type of suitable gauge (see Fig. 2 – page 17);
• Place the oven in the cabinet and screw the 4 screws fully down, using the holes provided in the facia, visible when the oven door
is opened. Make sure that the screws are inserted towards the centre of the wood in the cabinet: (see Fig.1-3-page 17). Before fi xing
the screws, also ensure that the oven is correctly aligned with the fl oor with the aid of a spirit level.
• An opening in the top of the tall unit, or a 10 mm gap above the oven surround, should be provided to ensure adequate ventilation.
(see Fig. 1 - page 17).
• If the oven is to be installed close to another appliance, check that there is no interference between the two devices when in ope-
ration.
• Once the appliance has been built in, no contact with electrical parts must be possible.
