12
Cleaning Stainless Steel
Care and cleaning of the oven you have purchased are important to keep the steel bright and uniform over time. The stainless steel
used for the manufacture of our ovens is Silver Ice, fi nished with a special anti-fi ngerprint treatment that keeps it shiny even after use.
We advise you never to use abrasive sponges, scouring pads, wire wool, acids or products which might scratch the surface. Clean
it with soft cloths and ordinary, absolutely non-abrasive washing-up liquid; creams are not recommended because they contain tiny
abrasive particles which might leave marks on the steel.
Cleaning Enamel and Glass
Enamel is a vitreous fi nish with excellent resistance to heat and acids. Like glass, it may be damaged by prolonged contact with acids, so
spills of tomato sauce, lemon and vinegar should be wiped off immediately. Use bicarbonate of soda or non-abrasive cream cleaner
for the most stubborn stains. Never use descaler products: they might cause irreparable damage to the enamel. Oven interiors are
also enamelled and must be cleaned using specifi c products, easily available from retailers. It is best to clean the oven after each
use, while still warm. We advise you not to allow dirt to build up over time since it is more diffi cult to remove layers of dirt and there is
a risk of leaving permanent marks on the enamel.
Cleaning the Door Glass
All ovens are fi tted with glass doors with innovative, extremely convenient characteristics. The full-glass on the inside can be removed
easily without the aid of any tools: the screw-free visible fi xing system guarantees that the door provides the easy cleaning only glass
can ensure. Proceed as follows to remove the glass in the oven door correctly.
• Fully open the door;
• apply gentle leverage with a coin or a fl at-head screwdriver in the two recesses in the bottom of the inside of the door simultaneou
sly;
• released from its seat, the glass can be extracted from the recess into which it is fi tted:
• After cleaning, repeat the same procedure in reverse order.
WARNING:
Take care to reassemble the pieces of glass in the correct order; the inside glass has a special heat-refl ecting fi nish!
Do not clean th
e glass door of the oven with rough, abrasive materials or sharp metal scrapers, since they may scratch the surface
and cause the glass to shatter.
4
.2. Maintenance
•
Disconnect the appliance from the electrical mains by disarming the fuses before carrying out any cleaning or servicing opera
tions.
•
In the event of failure, please fi rst of all check the fuses of the household electricity supply system.
•
If the problems are not caused by the power supply, kindly contact your Authorised Service Centre , stating the model of the appliance
and the serial number stated on the nameplate.
•
To ensure that the appliance’s safety characteristics are not impaired, all maintenance work must be carried out by authorised
personnel.
•
Improper maintenance work will result in forfeiture of warranty rights .
Changing the oven light bulb
To replace the oven light bulb, follow the instructions provided below:
1.
Switch the oven off and disconnect it from the power supply. The bulb is in the top right-hand corner of back wall of the oven;
2.
Make sure that the oven is cold and unscrew the glass cover;
3.
Unscrew the light bulb and replace it with another of the same type;
4.Screw the glass cover fi rmly back into place.
Removing the oven door
The door can be removed to clean the oven in an easier way following this instructions:
Changing the Oven Door Gasket
Always inspect the oven door gasket and order a replacement from the after-sales service without delay if worn.
Instructions
GB
1) Open the door completely.
2)
Turn the two levers “B” bringing them from position 1 to position 2.
3)
Close the door slowly to a stop, grab it with both hands from side to side, close it further and pull it by lifting it upwards.
4)
To replace the door you must follow the procedure in reverse order, insert the two hinges in their seats and open the
door completely.
5) Turn the two levers “B” bringing them back in position 1.
6) Close the door normally.
POSITION 2POSITION 1
