15
GB Installation
Technical data
HEATING ELEMENT POWERS
bottom element 1.5 kW
top element 0.7 kW
oven circular element 2.0 kW
grill 2.0 kW
fan 25 W
oven light 15 W
TOTAL ELECTRIC OVEN POWER
static oven 2.21 kW
fan oven 2.0 kW
multi-oven 2.21 kW
multifunction oven 2.7 kW
EQUIPMENT
Depending on the models, cooker may have:
- Self-cleaning enamelled liners
- Rotisserie
- Mechanical timer
- Digital-clock end of cooking timer
- Single-control end of cooking timer
- Electronic timer
For the ELECTRIC WIRING DIAGRAM see figure 2 at the back
of this manual.
The electrical power is stated on the nameplate. The nameplate
can be seen when the oven door is opened.
INSTALLATION
The appliance must be installed by qualified staff working in
accordance with the regulations in force.
The appliance is produced to EN 60 335-1, EN 60 335-2 and is
of built-in type, meaning that it must be installed in accordance
with the producer’s instructions.
The oven must be installed in a unit having materials (varnishes,
finishes, glues, etc.) resistant to a temperature of at least 100°C.
The dimensions of the compartment for built-in installation are
shown in Fig. 1.
Pre-fit the 4 screws (see fig. 3) using the tapered holes provided
in the front side visible with the oven door open, on the 4 square
black spacers, taking care that the tips of the screws just project
from the spacer.
Fit the oven into the unit and screw in the screws until
completely tight.
If the oven is to be installed close to other household appliances,
check that there will be no mutual interference during operation.
Their respective electrical connections must be separate.
Suitable ventilation should be assured by means of an opening
in the top of the column unit, or an opening of 10 mm above the
oven surround. See fig. 1.
CONNECTING TO THE ELECTRICAL MAINS
Before making the connection, check that:
- the mains voltage is as indicated on the nameplate;
- the earth connection is in good working order.
If the socket is not easily accessible, the installation engineer
must provide a switch with a contact breaking gap of 3 mm or
more.
If the appliance power lead is not fitted with a plug, use an
approved standard type, remembering that:
- the green-yellow wire must be used for the earth connection;
- the blue wire is the neutral;
- the brown wire is live;
- the lead must never touch hot surfaces over about 75 degrees
C;
- replacement leads must be of type H05RR-F or H05V2V2-F
of suitable size (see diagrams in fig. 2).
- if the appliance is supplied without lead, using type H05RR-F
or H05V2V2-F cable of suitable size (see diagrams in fig. 2).
IMPORTANT: the manufacturer declines all liability for damage
due to failure to comply with the regulations and standards in
force. Check that the appliance is correctly connected to the
earth (see diagrams in fig. 2 at the back of the manual).
Usable dimensions oven
Width cm. 41,0
Depth cm. 39,4
Height cm. 31,0
Volume l. 50
