35
Water connection
CAUTION:
• The Installation of the water supply must conform
to the local laws and regulations.
• The appliance is not suitable for hot water supply.
• Use the new supplied hose set to connect the
appliance to the water supply. Do not reuse old or
used connection sets.
• If the water pipe is new or long time not used,
ensure before connecting to the water system,
that the water is clear and free from contamina-
tion.
NOTE, the connection to the water mains may only
be made in accordance with DIN EN 1717 of the
drinking water ordinance. A suitable safety device
against drinking water contamination through back-
flow must be installed.
Notes on inlet hose safety system (delivery scope
depending on model)
The safety system consists of a double-walled inlet
hose. It guarantees to cut off the water supply when
leakage of the inner hose. Switching off the water
supply leads over an electronic contact.
Connect the water inlet hose (cold water connection)
NOTE:
The water pressure must be between 0.1-1.0 MPa.
With higher pressure: use a pressure regulator.
• Connect the water inlet hose to a water thread
with ¾“. Screw the hose firmly in the direction of
the screw thread; pay attention for a tight fit.
• Connect the other end of the inlet hose to the inlet
valve on the appliance back; pay attention for a
tight fit too.
Connect the water drain hose
NOTE:
The drain hose has a length of approx. 1.5 m and,
contrary to the recommendation, could be extended
to a maximum of 4 m with a suitable hose connector.
CAUTION:
To prevent backflow of contaminated water, the free
end of the hose must not come under the water level
of the drain.
• Connect the drain hose to a drainpipe with a min-
imum diameter of 40 mm; alternatively, the drain
hose can be fixed to a sink or directly to the
drainage.
• Always make sure that the hose is not bent or
squeezed. For this purpose, use the delivered
hose retaining bend (a).
• The hose must be installed at a height of min.
700 mm and max. 1250 mm above the floor.
• Secure the hose securely to avoid a change in
position and with it a water leakage.
Electrical connection
WARNING:
• The installation to the mains supply must conform
to the local standards and regulations.
• Improper connection may cause an electric shock!
• Do not use multiple sockets or extension cords.
• It is not allowed to modify the plug provided with
the appliance! If the plug does not fit properly to
the outlet, let a proper outlet install by an author-
ized specialist.
